Raising/Lowering
the Floor Tool
After preparing the floor (see previous
section), we are now ready to set the
controls to suit the cleaning conditions.
Before any settings can be applied,
ensure the brush deck is lowered.
Move the floor tool lever to its
lower position.
NOTE: Do not pull the machine
backwards with the floor tool in the
lowered position, this could possibly
damage the blades.
Raising/Lowering the Brush Deck
To tip the deck into the down position (Operating mode). Press in the brush deck locking pin (Fig.A)
and rotate the brush deck (Fig.B & C). To change to brush deck up position,
(Transit mode) simply lift the deck and the spring loaded locking pin will activate to hold the deck up.
Setting the Cleaning Controls
To start: hold down either trigger and press the yellow On / Off Switch once
Hour meter and battery power.
A
o
Vacuum On / Off
Machine Operation
B
Water On / Off
T 01460 68600
C
o
15
