Menu Map
Refer to the 4BAR Quad ILS product page on
Mode
4Ch
DMX Mode
6Ch
19Ch
ILS Mode
iLS
Static Colors
C--
Programs
P--
Auto Speed
S--
Dimmer
d--
Sound Mode
Snd
Sensitivity
SEnS
Custom
u--
Color Mixing
Control
SEt
Mode
DMX Linking
The 4BAR Quad ILS can work with a DMX controller. Instructions for connecting and configuring this product for DMX
operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from www.chauvetdj.com.
Starting Address
To ensure full access to all channels available in each DMX mode, the highest recommended DMX address is 494.
Master/Slave Connection
The 4BAR Quad ILS uses the DMX data connection for its Master/Slave mode. Information about configuring the
4BAR Quad ILS for Master/Slave operation is in the User Manual, which is available from the Chauvet website.
ILS Connection
The 4BAR Quad ILS uses the DMX data connection and the D-Fi USB for wireless connection to the Integrated Lighting
System (ILS) ecosystem (patent pending). For more information about configuring the 4BAR Quad ILS into ILS mode,
please refer to the User Manual available at www.chauvetdj.com.
IRC-6 (Infrared Remote Control)
The 4BAR Quad ILS can be operated with the CHAUVET IRC-6. For more information about the IRC-6, download
instructions for the IRC-6 or the 4BAR Quad ILS User Manual from www.chauvetdj.com.
3
QUICK REFERENCE GUIDE
www.chauvetdj.com
Programming Levels
d 1–509
iLS1–4
C 1–15
C 16
C 17
C 18
P 1–8
S. 1–100
L. 1–255
Snd1–8
u 0–100
r. 0–255
G. 0–255
b. 0–255
A. 0–255
S. 0–100
ir
SLAV
out
for the latest menu map.
Description
4-channel DMX mode
6-channel DMX mode
19-channel DMX mode
Sets ILS mode
Static colors
3000K color temperature
4500K color temperature
5600K color temperature
Automatic programs
Program speed for P 1–8
Dimmer
Sound-active programs
Sets sound sensitivity
Custom static colors
Combine red, green, blue, and amber
Strobe rate
on
Turns infrared on or off for footswitch or
IRC-6 control
oFF
Enable Master/Slave with other 4BAR Quad ILS products
dMX
Enable Master/Slave with legacy 4BAR products
4BAR Quad ILS QRG Rev. 1
