2 - MANAGEMENT OF THE FAN COIL WITH DC MOTOR THROUGH 0-10Vdc
THERMOSTAT (J1 - CLOSED)
B
Valve
ON
Only use
double-in-
sulation
connections
M1
N
Tab_1 (diagram "B")
Terminal box
Connections
Thermostat 0÷10 V
0-10 V
(Only use double-insulation connections)
M1
DC motor
J1
Jumper closed to select mode "0÷10 V"
Intake grille safety microswitch
S1
(to be connected only on some models, removing the bridge)
N - F
Board supply 230V - 50Hz
Y1
Solenoid valve 230V - 50Hz, 1A
Led
Mode/status indication
SW1
Machine configuration selector
EN - 6
0,8
2,0
0-10V
J1
H2O CFG
+V10-
SEL2
SW1
SEL1
MOUNT
LED
F
230V
50Hz
* *
Fan
Speed
MAX
Vdc
MIN
*
H2O
1,8
Closed
Y1
Do not use in configuration 0-10V
SIL, MIN, MED, MAX, EV
To the ground connection of the fan coil
Vdc
2,5
12
