DualAxis-Laser
Optional accessory:
SensoLite 310
Protection class IP 66
1
10
9
8
1
All-round marking groove
2
Receiver field for laser beam
3
SpotLite Marking LED
4
Vial
5
Fastening screw for levelling staffs
6
Universal mount
7
Binding screw / loudspeaker (rear
side)
8
Battery compartment (rear side)
9
Control panel
10 LC-Displays (front and rear side)
Note: The laser receiver has two tolerance settings: Precision and free-hand setting.
22
All manuals and user guides at all-guides.com
2
3
6
7
i
ENGLISH
11
12
4
13
14
15
16
17
5
18
11 Display measuring range
selection
12 Hand receiver above laser level
13 Precisely on laser level
14 Hand receiver below laser level
15 Volume indicator
16 Low battery indicator
17 Hand receiver mode /
Switch: Precision range
Free-hand range
18 Volume adjustment
