PITCHING INSTRUCTIONS (OPTIONAL)
O1
Storm Roof Pole
Slide the included awning bracket pad into place using the beading located in the rear center
of the roof. One in place (center) lock the bracket pad in place by pushing the push bottom in.
This locks the bracket pad in place and is now left there and does not need to be removed.
Insert the hook on the end of the roof pole into the bracket pad and extend the pole until the
flat end goes into the webbing pocket located at the top of the air tube at the front of the
awning. The pole should not be over tensioned, but have just enough tension to give the roof
extra tension and ensure that the front air tube cannot be blown backwards.
Storm Leg Pole
Place the flatted end of the storm pole into the webbing pocket to the front of the air tube.
Extend the pole down to the ground until it touches the ground. Again, do not over
tension this pole as it is disfigure the shape of the air tube and
cause issues with your awning.
O2
Rear Pole Kit
Take one of the rear poles and place the flatted end into the pocket in the top corner of the
side panel and extend the leg until it is touches the ground.
Push the pole against the pad and the pad will be pushed against your caravan, motorhome
or vehicle. This creates the seal against your vehicle.
The pole should be tight enough to hold the pole in place. But must not be over tensioned as
it could caused damage if over tensioned.
Tie the pole in place using the Velcro tie backs along the rear of the panel.
OPTIONAL
OPTIONAL
