All manuals and user guides at all-guides.com
GB
Technical data
Model
Gross capacity (l)
Net capacity (l)
Width (mm)
Height (mm)
Depth (mm)
Energy consumption
(kWh/24h)
(kWh/year)
Energy class, according to EU standards
Rated power (A)
Weight (kg)
Installing the appliance
Transportation, unpacking
It is recommended to deliver the appliance in origi-
nal packaging, in vertical position considering the
protective warning on packaging.
After each transportation the appliance must not be
switched on for approx. 2 hours.
Unpack the appliance and check if there are damages on
it. Report possible damages immediately to the place you
bought it. In that case retain packaging.
Cleaning
Remove every adhesive tape, which ensure the parts not
to move in the appliance.
Wash the inside of the appliance using lukewarm water
and mild detergent. Use soft cloth.
After cleaning wipe out the inside of the appliance.
Placement
The ambient temperature has an effect on the energy con-
sumption and proper operation of the appliance. When
placing, take into consideration that it is practical to oper-
ate the appliance between ambient temperature limits
according to the climate class that is given in the chart
below and can be found in the data label.
Class of climate
SN
N
ST
If the ambient temperature goes below the lower data the
temperature of the cooling compartment can go beyond
the prescribed temperature.
If the ambient temperature goes beyond the upper data
this means longer operating time of the compressor,
breakdown in the automatic defrosting increasing temper-
ature in the cooling compartment or increasing energy
consumption.
38
Downloaded from www.vandenborre.be
Instructions for the Installer
ZRA 620 CW
Fresh food comp.: 206
Fresh food comp.: 195
550
1050
600
0,43
157
0,5
41
Ambient temperature
+10 ... +32 °C
+16 ... +32 °C
+18 ... + 38 °C
A
When placing the appliance ensure that it stands level. This
can be achieved by two adjustable feet (1) at the bottom in
front. 1-1 piece of distance washer (2) are accessories of
the adjustable feet. If levelling the appliance requires,
these washers can be removed.
The plastic bag of accessories also contains two
spacers to be fitted into special holes in the back of
the appliance. Fit the spacers into the holes, taking
care to ensure that the arrow (A) is positioned as
shown in Figure. Then turn them through 45° (arrow
(A) vertical) until they lock into place.
45°
PR60
Do not stand the appliance on a sunny place or close to a
radiator or cooker.
If it is unavoidable because of furnishing and the appliance
has to be stood near a cooker take these minimum dis-
tances into consideration:
In case of gas or electric cooker 3 cm must be left,
when it is less put a 0,5-1 cm non-flam insulation
between the two appliances.
A
