4. CONTROLS
Key
Function
A
Turns the motor on/off at the first speed.
B
Decreases the operating speed.
C
Increases the operating speed.
D
Activates/Deactivates the motor at Intensive speed.
This speed is timed for 6 minutes. When the time is up, the system automat-
ically returns to the previous speed.
Long press when all loads are off (Motor+Light):
Activates/Deactivates the Activated Carbon Filters alarm.
E
24h Function
Activates/Deactivates the motor in the 24h mode, a speed that allows suction
of 10 minutes every hour, for a 24-hour cycle.
With the filters alarm in progress, pressing the button for approximately 3
seconds resets the alarm.
These signals are only visible with the motor off.
F
Delay Function
Activates the automatic shutdown delayed by 30'.
Ideal for eliminating any residual odours.
It can be activated from any position and is deactivated by pressing the but-
ton or by switching off the motor.
Long press when all loads are off (Motor+Light):
Activates/Deactivates the remote control.
Switches the lighting system on and off to maximum brightness.
G
Turns the lighting system on and off in Courtesy Light mode.
H
5. REMOTE CONTROL
• This appliance can be controlled us-
ing a remote control.
6. LIGHTING
• Please contact the Service Depart-
ment to change it ("Please contact
the service department to purchase
it").
LED
Displays the speed set.
Displays the speed set.
Displays the speed set.
Alternately displays HI and the re-
maining time once per second.
FC+Dot (2 Flashes)–Alarm Active.
FC+Dot (1 Flash)–Alarm Deactiv-
ated.
Displays 24 and the lower right dot
flashes once per second while the
motor is in operation.
It is disabled by pressing the key.
FF flashes three times.
At the end of the procedure, the
previously displayed signal goes
out:
FG signals the need to wash the
metallic grease
filters. The alarm goes into opera-
tion after 100 hours of
actual work of the hood.
FC signals the need to replace the
activated carbon filters
and the metal grease filters must
also be washed. The alarm goes
into operation after 200 hours of
actual hood work.
Displays the operating speed and
the lower right dot flashes once
per second.
IR+Dot (2 Flashes)–Alarm Active.
IR+Dot (1 Flash)–Alarm Deactiv-
ated.
-
-
11
