4. WARRANTY
Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or
workmanship for the duration of the "warranty period". The warranty shall be effective for two years from the date of installation.
Hoshizaki's liability under the terms of the warranty are limited and shall exclude routine servicing, cleaning, essential
maintenance and/or repairs occasioned by misuse and installations not in accordance with Hoshizaki guidelines.
Warranty repairs should be completed by an approved Hoshizaki dealer or service agency using genuine Hoshizaki components.
To obtain full details of your warranty and approved service agency, please contact your dealer/supplier, or the nearest Hoshizaki
Service office:
Europe
U.K./Ireland - Hoshizaki UK
TEL: +44 (0)845 456 0585
FAX: +44 (0)1462 499080
Holland - Hoshizaki Europe
TEL: +31 (0)20 6918499
FAX: +31 (0)20 6918768
Belgium/Luxemburg - Hoshizaki Belgium
TEL: +32 (0)2 7123030
FAX: +32 (0)2 7123031
Germany/Switzerland/Austria - Hoshizaki Deutschland
TEL: +49 (0)2154 92810
FAX: +49 (0)2154 928128
Other than Europe
Hoshizaki Singapore
TEL: +65 6225 2612
FAX: +65 6225 3219
Hoshizaki Lancer
TEL: +61 8 8268 1388
FAX: +61 8 8268 1978
SPECIFICATIONS
Model
Type
Power Supply
Electric Consumption
Ice Production per 24h
Dimensions
Refrigerant
Weight
Ambient Temp
Water Supply Temp
Water Supply Pressure
Voltage Range
Note: The above specifications are for the representative models.
IM-240ANE
Air-cooled, cube ice
1 phase 220 - 240V 50Hz
1320W
220kg (5mm) / 240kg (15mm)
(ambient temp 10°C, water temp 10°C)
560mm(W) x 700mm(D) x 880mm(H)
R404A, 500g
Net: 80kg (Gross: 91kg)
1 - 40°C
5 - 35°C
0.07 - 0.78 MPa (0.7 - 8 bar)
Rated voltage ± 6%
France - Hoshizaki France
TEL: +33 (0)1 48639380
FAX: +33 (0)1 48639388
Spain/Portugal - Hoshizaki Iberia
TEL: +34 (0)93 4780952
FAX: +34 (0)93 4780900
Other countries - Hoshizaki Europe
TEL: +31 (0)20 6918499 or +44 (0)845 456 0585
FAX: +31 (0)20 6918768 or +44 (0)1462 499080
Hoshizaki Suzhou
TEL: +86 512 62807850
FAX: +86 512 62807860
IM-240AWNE
Water-cooled, cube ice
1 phase 220 - 240V 50Hz
1300W
230kg (5mm) / 240kg (15mm)
(ambient temp 10°C, water temp 10°C)
560mm(W) x 700mm(D) x 880mm(H)
R404A, 450g
Net: 83kg (Gross: 94kg)
1 - 40°C
5 - 35°C
0.07 - 0.78 MPa (0.7 - 8 bar)
Rated voltage ± 6%
7
ENGLISH
