Assembly Instructions
1. Position the housing (2) with the open side facing
upwards.
NOTE:
It is best to place a blanket underneath so that the
housing is not damaged.
2. Pass the connection cable through the hole of the
base plate (3) so that the mains plug is located on the
underside of the base plate (Illustration A).
3. Place the base plate on the housing. Please use the
guide pin to fi x it in place.
4. Screw the base plate together with the six fastening
screws (4).
5. Thread the cable into the recess provided on the base
plate.
6. Press the strain relief fi rmly into the position provi-
ded.
7. Attach the mains cable to the base plate with the
two screws (5).
8. Now turn the fan over and place it on a suitable solid
surface.
Remote Control
• Remove the remote control from the compartment
on the back of the device (Illustration B).
• The cordless remote control has a range of up to 10
meters. When using the remote control, please ensure
that there are no obstacles placed between it and the
sensor on the device.
Inserting the Batteries
NOTE:
The button cells in the battery compartment of the
remote control have been secured for transport with a
foil. This prolongs the life of the batteries. Before initial
use please remove this foil so that the remote control is
ready for operation (Illustration C).
If the range of the remote control is reduced during use,
please proceed as follows:
• Open the battery compartment on the back of the
remote control.
• Replace the button cells by two batteries of the same
design (LR 41). Ensure correct polarity.
• Then close the battery lid.
CAUTION:
Batteries are not to be disposed of together with
domestic wastes. Dispose of the used batteries at the
relevant collection bin or at your dealer's.
05-TVL 5537 AEG.indd 24
05-TVL 5537 AEG.indd 24
All manuals and user guides at all-guides.com
• Do not expose the batteries to high temperatures
• Keep batteries away from children. They are not a
• Do not open the batteries by force.
• Avoid contact with metallic objects. (Rings, nails,
• As a result of a short-circuit batteries may heat up
• For your own safety the battery poles should be
• If a battery leaks do not rub the liquid into your
Putting into Service
Electrical Connection
1. Before inserting the plug into the socket. Make sure
2. Connect the device to a duly installed 230 V/50 Hz
Use
• The buttons are to be found both on the device
• For the meaning of the symbols please see the
• Every press of the buttons changes the function
• The device has a memory function: the last para-
Operating Mode Display
(Meaning of the colours of the LED control lamps on the
device)
Display on the Device Symbol Function
On
Off
Slow
Medium
Fast
WARNING:
or direct sunlight. Never throw batteries into the
fi re. There is a danger of explosion!
toy!
screws et cetera.) There is a danger of short-circui-
ting!
considerably or even catch fi re. This may result in
burns.
covered with adhesive strips during transport.
eyes or mucous membranes. If hands come into
contact with the liquid they should be washed
thoroughly and eyes rinsed out with clear water; if
symptoms persist please consult a doctor.
that the mains voltage to be used matches that of
the device. You can fi nd this information on the
nameplate.
protective contact socket.
NOTE:
itself and on the remote control.
following table.
and is confi rmed by a sound.
meters set are stored. When it is switched on again,
the fan starts up with the last settings.
= green
Start or stop the fan
= light off
= red
Speed setting:
= orange
low / medium / fast
= green
