12 Cleaning and care
Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They can damage the housing and can cause the product to malfunction.
– Do not submerge the product in water.
Clean the outside of the weather station using a dry, soft, lint-free, clean cloth. Do not press too
hard on the display to prevent scratch marks or malfunctions. Use a long-haired, soft and clean
brush and a hoover to remove dust from the weather station.
Dirt deposits on the outdoor sensor can be removed using a soft cloth slightly moistened with
lukewarm water.
13 Disposal
13.1 Product
This symbol must appear on any electrical and electronic equipment placed on the
EU market. This symbol indicates that this device should not be disposed of as
unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back
of waste. Conrad provides the following return options free of charge (more details on our
website):
in our Conrad offices
at the Conrad collection points
at the collection points of public waste management authorities or the collection points set
up by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in
countries outside of Germany.
13.2 (Rechargeable) batteries
Remove batteries/rechargeable batteries, if any, and dispose of them separately from the
product. According to the Battery Directive, end users are legally obliged to return all spent
batteries/rechargeable batteries; they must not be disposed of in the normal household waste.
Batteries/rechargeable batteries containing hazardous substances are labelled with
this symbol to indicate that disposal in household waste is forbidden. The abbrevi-
ations for heavy metals in batteries are: Cd = Cadmium, Hg = Mercury, Pb = Lead
(name on (rechargeable) batteries, e.g. below the trash icon on the left).
Used (rechargeable) batteries can be returned to collection points in your municipality, our
stores or wherever (rechargeable) batteries are sold. You thus fulfil your statutory obligations
and contribute to environmental protection.
Batteries/rechargeable batteries that are disposed of should be protected against short circuit
and their exposed terminals should be covered completely with insulating tape before disposal.
Even empty batteries/rechargeable batteries can contain residual energy that may cause them
to swell, burst, catch fire or explode in the event of a short circuit.
14 Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this
product conforms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
conrad.com/downloads
Enter the product item number in the search box. You can then download the EU declaration of
conformity in the available languages.
15 Technical data
15.1 Power supply
Input voltage/current
Weather station ............................ 3x 1.5 V AAA batteries
Outdoor sensor ............................. 2x 1.5 V AA batteries
15.2 Measurement range and accuracy
Measurement range
Weather station ............................ -10 to +50 °C, 1 – 99% RH
Outdoor sensor ............................. -40 to +60 °C, 1 – 99% RH
Accuracy
Temperature ................................. +/- 1 °C (+/- 1 °C at +10 to +30 °C)
Humidity ........................................ +/- 8% (+/- 5% at 40 – 70% RH)
15.3 Wireless module
Transmission frequency................ 431.92 – 435.92 MHz
Transmission power...................... 4.11 dBm
Transmission range ...................... max. 100 m (free-field)
Transmission interval .................... CH1 = 114 seconds, CH2 = 134 seconds,
......................................................
15.4 Ambient conditions
Weather station
Operating conditions ..................... 0 to +40 °C, 20 - 90 % rH (non-condensing)
Storage conditions ........................ -10 to +60 °C, 30 - 80 % rH (non-condensing)
Outdoor sensor
Operating conditions ..................... 0 to +40 °C, 20 - 90 % rH (non-condensing)
Storage conditions ........................ -10 to +60 °C, 30 - 80 % rH (non-condensing)
Protection class (outdoor sensor) .. IP54
15.5 Other information
Weather station
Dimensions (W x H x D) ............... 65 mm x 100 mm x 25 mm
Weight .......................................... 98 g
Outdoor sensor
Dimensions (W x H x D) ............... 38 mm x 100 mm x 19 mm
Weight .......................................... 32 g
www.
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2024 by Conrad Electronic SE.
4
CH3 = 158 seconds
*3208236_V2_0924_02_VTP_m_EN
