SLIMCOOL
ALL EURO 5 MODELS BEHIND THE GLOVE COMPARTMENT
Take care not to invert polarities when connecting the unit to the power supply; the display does not come
on and the unit does not work.
Centrifugal
blower
2,6 Amp.
Az
Blue
N
Black
R
Red
V
Green
B
White
A
Yellow
Na Orange
M
Brown
Compressor
electronic
module
Wiring Diagram
IMPORTANT NOTE!
Electronic
control
Compressor
15
Return
air sensor
NTC 10KΩ a 25º
Comsuption 30 mAmp.
Condenser
fan
2,9 Amp.
PWM.
Compressor
electronic
module
EN
Compresor
