Anti-splinter insert
/
Saw blade
:
Contact guard
∙
Intended use
The product described is a hand-held, electrically powered orbital-action jig saw. It is designed for
cutting plastic, wood and metal materials, drywall board and gypsum fiberboard.
The product is equipped with a removable connector for an optional vacuum cleaner / dust removal
hose. This connector is designed to fit standard suction hoses. In order to connect the suction hose
to the product, use of a suitable adapter may be necessary.
The tool may be operated only when connected to a power source providing a voltage and frequency
in compliance with the information given on the type identification plate.
▶
Use this product only with saw blades equipped with a T-shank.
Possible misuse
• Use of the product to cut off tree branches or to cut the trunk of a tree is not permissible.
• Use of the product to cut hazardous materials is not permissible.
• Use of the product in a damp or wet environment is not permissible.
Dust blower
The dust blower directs a jet of air toward the saw blade in order to keep the cutting line free of dust.
Stroke rate
The stroke rate can be adjusted by turning the thumbwheel. Position 1 corresponds to 800 strokes
per minute and position 6 corresponds to 3000 strokes per minute.
Depending on how far the on/off switch is pressed, the stroke rate begins at 75 strokes per minute
and increases to the stroke rate set by the thumbwheel.
4 orbital-action settings
The 4 orbital-action settings allow cutting performance and quality of cut to be adjusted to suit the
material to be cut. The orbital-action adjustment lever is used to set the power tool to one of the 4
settings.
The lower the orbital-action setting, the finer and cleaner the cut edges will be. The optimum setting
can be determined by carrying out practical tests.
Status
Position 0
Position 1
Position 2
Position 3
2
Lockbutton
The lockbutton has three positions.
1. The middle position is the normal position: The lockbutton can be seen on the left and on the
right. In this position, for example, the stroke rate can be adjusted.
The on/off switch can be pressed and released.
2. The lockbutton can be seen only on the left: Transport position (the tool cannot start)
The on/off switch is locked and cannot be pressed.
3. The lockbutton can be seen only on the right: After the tool has been switched on (on/off switch
fully pressed), the lockbutton can be pushed to the right to lock the switch in the "on" position. To
release the lock, press the on/off button again.
*2143763*
2143763
Guard
$
Tool holder
£
Saw blade release lever
|
Meaning
No orbital action
Low orbital action
Medium orbital action
High orbital action
