LIGHT MODES:
Press the button to alternate the functions: High -> Mid
-> Low -> Slow flash -> Strobe -> OFF
USE OF THE LAMP:
Lamp is charged using 5V DC USB power outlet. Micro
USB input (3.) is located under protective lid
Charging cable is included with the lamp
Lamp have built in overcharge protection circuit
Please fully charge the lamp before use
Lamp can be used hanging from the hanger, standing
using the hanger as support or attached to magnetic
surfaces using the built in magnet
Lamp can be cleaned with water and a damp rag
Lamp is water resistant to IPx4
Do not use corrosive liquids to clean the lamp
Do not stare into the light source
Do not modify the product
LIGHT SOURCE: 3W LED
This product contains a light source
of energy efficiency class F.
Light source and control gear is not repla-
ceable. This would introduce weak points
in the construction, that could reduce the
lifetime of the product.
INSTRUCTION FOR REMOVAL OF LIGHT SOURCE
AND CONTROL GEAR BY MARKET SURVEILLANCE
AUTHORITIES:
1) Use knife or similar tool to pry off lens
2) Remove 4 pcs screws to allow removal of the black
part, including the light source board
3) Cut wires to light source board to remove the required
components for testing
2
INSTRUCTION FOR DISASSEMBLY OF LAMP
FOR DISPOSAL OF COMPONENTS WHEN
LAMP HAVE REACHED THE END OF ITS
USABLE LIFE:
- See step 1-3 above
4) Cut wires to allow removal of battery. Dispose of
battery according to local regulations
5) Remove screws to allow removal of electronics on
circuit board. Dispose of electronics according to local
regulations
6) Dispose of remaining components according to local
regulations
TECHNICAL DATA:
5V
, 3W
Input 5V:
, 1A
Battery: 3.7V
Class 3 appliance
, 1800 mAh
