6.
Bluetooth 4.0, transmission distance: ≤8 meters;
7.
Battery capacity: 600mAh;
8.
Standby time: 50 days when fully charged;
9.
USB data cable: 1.60 m in length;
CONDITIONS OF USE / INSTRUCTIONS FOR USE
Wireless connection instructions for Switch
●
Connecting to the host for the first time: Click 'Handle' -> 'Change Grip/Sequence' on the Switch
the handle pairing mode;
●
Press the handle B+HOME button for 3 seconds to enter the pairing state, the LED flashes quickly in the form of a marquee, and
the handle is automatically paired with the host. After the connection is successful, the corresponding LED light is always on!
●
You have successfully connected, you can directly press the HOME button, the LED flashes slowly in the form of a marquee,
automatically wakes up the host and reconnects!
Wired connection instructions for Switch™
Use the equipped USB cable to connect the handle and the Switch™ host. After the connection is successful, the corresponding LED light is
always on!
TURBO Function
The action keys include A/B/X/Y/L/ZL/R/ZR, and the TURBO function can be set manually;
Setting method
I.
Press and hold the action key, then lightly press the TURBO key to turn on, and lightly press the TURBO key again to realize the
automatic TURBO function, tap the TURBO key again, the TURBO function of this action key is turned off;
II.
Clearing method: first press the down arrow key, and then press the minus key, the handle vibrates once to indicate that this
command has been executed, and the Turbo function of all keys is cleared;
TURBO speed editing
1.
Three speeds can be set: the first gear continuously fires 5 times per second; the second gear continuously fires 10 times per
second, the third gear continuously fires 20 times per second;
2.
Power on for the first time (the next power on after the reset button is pressed is regarded as the first power on), the default is
second gear;
3.
Press the T key and the arrow up key at the same time, and the handle vibrates once, indicating that the burst speed is
successfully increased by one gear. Press the T key and the down arrow key at the same time, the handle vibrates once, which
means that the continuous speed is successfully reduced by one gear.
Motor Function : Motor vibration intensity setting
●
Three speeds can be set: the first gear is 100% strength; the second gear is 70% strength; the third gear is 30% strength;
●
Power on for the first time (the next power on after the reset button is pressed is regarded as the first power on), the default is
the second gear 70% intensity;
●
Press and hold the 4 L/ZL/R/ZR buttons on the side at the side at the same time for 1 second, and the motor will vibrate in three
gears to cyclically adjust;
Handle charging/sleeping/wake-up/shutdown functions:
➀Charging function of the handle
1.
When the power is low, the LED indicator flashes quickly;
2.
When charging, the LED indicator light flashes slowly;
3.
When it is full during work, the corresponding LED indicator will be on for a long time;
4.
When it is fully charged after shutdown, the corresponding LED indicator will go out;
②Handle wake-up/shutdown function:
1.
In the power-on state, press and hold the HOME button for 5 seconds, the product will shut down and all the LED indicators will
go out;
2.
When you need to use it again press the HOME button for 1 second to wake up the handle, and you can connect back.
TM
TM
main menu interface to enter
