THERMO TRANSMITTER
15
(15) Thermo transmitter
(16) Status LED thermo transmitter
(17) Learn button thermo transmitter
(18) Connection thermo transmitter
(19) Battery compartment 2 x AA
T = Thermal sensor
B = Mounting bracket
(a) Holes for screws
(b) Hole for thermal sensor
24
All manuals and user guides at all-guides.com
19
B
a
The temperature sensor must
T
extend into the exhaust gas
stream by at least 30 mm.
b
Flue pipe
(Figure 3)
16
17
18
Distance to the fireplace
maximum 150 cm!
