• If the battery is too hot, the charging process will
start automatically after it cools down.
• If, on the other hand, the battery has a normal
temperature but is totally discharged, the char-
ger will check if it still draws power or it if is
already defective.
• If the battery can be recovered, the yellow light-
emitting diode will glow continuously after some
time, signalling the successful charging process.
• If the yellow light-emitting diode fl ashes, the bat-
tery is defective and needs to be disposed of; see
also "Note on disposal within the EU" later on in
these instructions.
General handling of the device
Caution!
• A collet chuck is inserted in the spindle of the
device ex works!
• When using collets, always make sure that the
collet chuck and the utilised tool have the same
shaft diameter! The arbour of the tool must be
seated fi rmly and securely in the collet!
• When storing the bits and cutters, make surethey
are reliably protected from damage!
Clamping and changing the tool (Fig. 4)
Caution!
Always remove the battery before exchanging tools!
1. Turn sleeve nut 1 slightly whilst simultaneously
pressing the lock button until it engages.
2. Release the nut for a few rotations and exchange
the tool.
3. If the collet chuck needs to be replaced as well,
screw off the nut entirely, exchange the collet and
screw on the nut lightly by hand.
4. Insert the bits and cutters and tighten with the
supplied wrench 3.
The IBS/A industrial drill/grinder was ergonomically
designed to make it easy to handle and guide pre-
cisely. The thread of the collet chuck nut is counter-
sunk in the machine housing. Using a drill chuck is
not possible for this reason.
Working with the device
1. To activate, operate the rotary button 1 (Fig. 1)
and set the right speed for the work. Applicable
in principle, tools with smaller diameters must
be operated at higher speeds, and tools with
greater diameters at lower speeds in order to
achieve optimal results.
2. If you would like to guide the device by hand
while working, hold it like a ballpoint pen whilst
milling or engraving. Do not cover the ventilation
slots (Fig. 5). For coarser work, hold the device
like the shaft of a hammer (Fig. 6).
6 Maintenance, cleaning and care
Caution!
Remove the battery from device before any
assembly, adjustment, maintenance measure
or repair!
Every device is dirtied by dust when working with
wood. Cleaning is therefore essential. To ensure a
long service life, however, the machine should be
cleaned with a soft cloth or brush after each use.
Mild soap or other suitable cleaning agent may be
used in this context. Solvents or cleaning agents
containing alcohol (e.g. petrol, cleaning alcohols
etc.) should be avoided, since these can attack
plastic casings.
Always keep the apertures required for cooling the
motor free of dust and dirt.
Service note
Please note: The mains power input for the charger
may only be replaced by our Proxxon Service De-
partment or a qualifi ed specialist!
7 Accessories
For more detailed information on accessories,
please request our device catalogue from the
address specifi ed on the last page in the warranty
information.
Please note in general:
Proxxon bits and cutters have been designed to
work with our machines, which makes them op-
timal for their use.
We will not assume any liability whatsoever for the
safe and proper function of our devices when using
third-party bits and cutters!
Note!
- 17 -
