OBJ_BUCH-340-006.book Page 23 Wednesday, August 28, 2013 5:05 PM
Lock the grinder spindle with
the spindle lock button 2. To
24
tighten the quick-clamping
nut, firmly turn the grinding
disc in clockwise direction.
A properly attached, undam-
aged quick-clamping nut can
be loosened by hand when
turning the knurled ring in an-
ticlockwise direction.
Never loosen a tight quick-
clamping nut with pliers. Al-
ways use the two-pin span-
ner. Insert the two-pin span-
ner as shown in the
illustration.
Approved Grinding Tools
All grinding tools mentioned in these operating instructions
can be used.
-1
The permissible speed [min
] or the circumferential speed
[m/s] of the grinding tools used must at least match the values
given in the table.
Therefore, observe the permissible rotational/circumferen-
tial speed on the label of the grinding tool.
max.
[mm]
[mm]
D
b
d
115
6
125
6
D
150
6
b
D
115
–
125
–
d
75
30
M 14
b
D
Bosch Power Tools
Rotating the Machine Head
Before any work on the machine itself, pull the mains
Completely unscrew the four screws. Rotate the machine
head carefully, without removing it from the housing, to the
new position. Screw in and tighten the four screws again.
Dust/Chip Extraction
Dusts from materials such as lead-containing coatings,
Prevent dust accumulation at the workplace. Dusts can
-1
d
[min
]
[m/s]
22.2
11000
80
22.2
11000
80
Operation
22.2
9300
80
Starting Operation
–
11000
80
Observe correct mains voltage! The voltage of the pow-
–
11000
80
When operating the machine with power from mobile genera-
11000
45
tors that do not have sufficient reserve capacity or are not
equipped with suitable voltage control with starting current
amplification, loss of performance or untypical behavior can
occur upon switching on.
Please observe the suitability of the power generator being
used, particularly with regard to the mains voltage and fre-
quency.
plug.
The machine head can be
rotated with respect to
the machine housing in
90° steps. In this man-
ner, the On/Off switch
can be brought into a
more convenient posi-
tion for special working
situations, e. g., for cut-
ting operations using the
cutting guide with dust
extraction protection
guard 21 or for left-hand-
ed persons.
some wood types, minerals and metal can be harmful to
one's health. Touching or breathing-in the dusts can cause
allergic reactions and/or lead to respiratory infections of
the user or bystanders.
Certain dusts, such as oak or beech dust, are considered
as carcinogenic, especially in connection with wood-treat-
ment additives (chromate, wood preservative). Materials
containing asbestos may only be worked by specialists.
– As far as possible, use a dust extraction system suita-
ble for the material.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the
materials to be worked.
easily ignite.
er source must agree with the voltage specified on the
nameplate of the machine. Power tools marked with
230 V can also be operated with 220 V.
English | 23
1 609 92A 0E3 | (28.8.13)
