GB
With the Super Fog you have purchased a ultrasonic humidifier for rooms, terrariums,
green houses, winter gardens and other applications.
The device operates a membrane that nebulizes water through ultrasonic vibration.
The result is a humid fog which looks very attractive and raises the humidity of
the surrounding.
Instructions for Use:
• Install the device in a suitable place and make sure it has a secure footing.
• Attach the tube to the outlet and install the other end of the tube inside of the
terrarium.
• The maximum difference in height should not be more than 2meters.
• Remove the water tank and fill with water through the removable opening
• Place the water tank properly on the device.
• The humidifying degree can be adjusted with the Power switch, If turned on, a
green light will show.
• It is recommended to use a timer or even better a hygrostat or other control unit.
Continuous use is not recommended,
• It is recommended to use distilled water to ensure a long life.
Safety Instructions:
• Do not turn on if water tank is empty.
• Do not add water through the fog outlet!
• Cut power if you remove the water tank or before moving the device
• Do not use the device if the temperature is in the freezing range
• Do not put additives into the water
• Do not use hard devices for cleaning the membrane to avoid damage
• Keep the device away from electromagnetic sources
• Do not open the device or make any technical changes
• Do not use the device in places of high humidity
Attention: Do not use the device inside a terrarium! The humidifier is
designed for installation outside of the terrarium and not suitable for
use in high humidity surroundings!
Failure Checking and Fixing:
If your humidifier fails to work:
Failure
Indicator lamp not on, no fog
Fog has strange smell
Low fogging power
Abnormal noise
Indicator is showing red light
Should the problem reside, contact your retailer.
Operating Instructions – Super Fog Humidifier
Failure analysis
No power
New device
Dirty or old water
Dirty or damaged membran
Dirty or damaged membran
Power of Fogger is reduced through power switch
Collected condensate is blocking the tube
Low water in tank
Vibrations due to unsecure footing
Low water in tank
Floating ball does not float
Changing the membrane:
The membrane wears out over time and needs to be replaced. The replacement of the
membrane can only be made by a professional. Please contact us if your membrane
needs to be replaced. This is not covered by any warranty!
Warranty:
The implied warranty applies. The warranty does not cover the membrane. The war-
ranty expires in case of modification and repair attempts as well as damaging by
force or inappropriate usage.
Neither a guarantee nor any liabilities for detriments or consequential damages in
relation with this product will be assumed.
In case of warranty claims or repairs contact your specialist dealer.
Technical Data:
Humidifying Performance
Water Tank capacity
Noise:
Voltage:
Powet Consumption
Dimensions
Tube length
Weight
Solution
Connect power, turn on
Open the water tank and ventilate for 12h in a cool place
Change water and clean tank/device
Change water and clean tank/device
Carefully clean membrane
Turn on the power through power switch
Remove condensate and prevent the sagging of the tube
Refill water tank
Place device on noise reduction surface
Refill water tank
Move the ball slightly
Fog Outlet
Water Tank
Adaptor for Tube
Water inlet
Floating Ball
Power Switch
<= 300 ml/h
<= 30db(A)
100 – 240 V, 50 Hz
<= 33W
19,5x18,5x27,0 cm
95 – 225 cm
2,1 L
0,8 kg
3
