USB connection
Detailed information on the phone's energy
consumption and possible energy savings by
using the power saving function can be found in
the complete help/operating instructions: https://
bit.ly/4jDmN1R
Technical Data for Headset Connections
Microphone current consumption
Microphone sensitivity
Loudspeaker impedance
Loudspeaker sensitivity at 1 kHz
Sound level threshold
Initial Commissioning
1.
Mount the device base (2 different tilt angles) → A1
2.
Connect the telephone → A2
The Message key flashes. The company logo is first shown on the
display for 2 - 3 minutes, followed by information on the progress of
provisioning.
The IP address of the phone is shown at the top right of the display.
3.
Write down the IP address.
Note: The description applies from firmware version 2.4.
Note: During initial commissioning with provisioning (e.g. on a
COMtrexx), the phone starts up ready for use with the start screen.
Otherwise, the telephone waits for further entries.
Further information – also for commissioning
without provisioning – can be found in the
complete help/operating instructions: https://
bit.ly/3VJWonU
Environmental notices
To protect the environment, please make sure that the packaging materials
are properly disposed of.
If the Auerswald device is taken out of use (retired), make sure that it is
properly disposed of (it must not be disposed of with normal household
waste).
Consult your local governmental authorities for information about how to
dispose of the device in a proper and environmentally safe way. If you would
1x for connecting a
COMfortel D-XT20/D-XT20i
key extension module
max. 0.5 mA
-43 dB
100 Ohms
19.5 +/- 3 dBPa/V
24 dBPa
