Installation
1. Use the back of the flash and sounder case as a template for marking the
drill holes (2). Drill the holes for the fixing screws.
2. Pull the connector cable through the opening provided.
3. Fix the rear of the casing and the removal contact (7) to the wall.
4. Connect the cables to the terminal block (8) as described .
5. Replace the protective cover (9) and the casing cover (1) and tighten the
fixing screws.
Connections
Use only shielded and grounded cables.
Connect the flash and sounder cables to the corresponding control or switching
outputs of your alarm system. Check the total power consumption. You can also
incorporate the cover contact into the tamper line of your alarm system.
Technical data
Voltage supply
Max. power consumption (without
flash)
Max. power consumption (with flash)
Acoustic alarm
Protection type
Operating temperature
Dimensions (WxHxD)
Weight with flash / without flash
The manufacturer reserves the right to make technical modifications without
prior notice.
IMPORTANT: Make sure you connect the cables to the right
polarity, otherwise the flashlight may be irreparably damaged.
10–15 V DC
340mA
750mA
110dB @ 1m
IP34
-25 to +55°C
190 x 310 x 120 mm
1,850g / 1,700g
