16 | English
Do not use the saw above the level of your head. Doing
u
so will mean you have inadequate control of the power
tool.
Use suitable detectors to determine if utility lines are
u
hidden in the work area or call the local utility com-
pany for assistance. Contact with electric lines can lead
to fire and electric shock. Damaging a gas line can lead to
explosion. Penetrating a water line causes property dam-
age or may cause an electric shock.
Secure the workpiece. A workpiece clamped with
u
clamping devices or in a vice is held more secure than by
hand.
Hold the power tool firmly with both hands and make
u
sure you have a stable footing. The power tool can be
more securely guided with both hands.
Do not operate the power tool when stationary . It is
u
not suitable for operation with a saw table.
Do not use HSS saw blades. Such saw blades can easily
u
break.
Do not saw any ferrous metals. Hot chips may ignite the
u
dust extractor.
Wear a dust mask.
u
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Always wait until the power tool has come to a com-
u
plete stop before placing it down. The application tool
can jam and cause you to lose control of the power tool.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for making straight cuts in wood
with and against the grain and mitre cuts in wood while rest-
ing firmly against the workpiece. With suitable saw blades,
you can also saw thin-walled non-ferrous metals (such as
profiles), lightweight materials and plastics.
The power tool must not be used to cut ferrous metals.
1 609 92A 7XT | (03.08.2022)
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) On/off switch
(2) Lock-off switch for on/off switch
(3) Lever for saw blade change
(4) Auxiliary handle (insulated gripping surface)
(5) Hex key
(6) Cutting depth scale
(7) Base plate
(8) Adjustable cutting depth indicator
(9) Scale for mitre/bevel angles
(10) Wing bolt for parallel guide
(11) Wing bolt for mitre/bevel angle preselection
(12) Button for mitre/bevel angle 47°
(13) Adjustable viewing window for dust extraction
(14) Parallel guide
a)
(15) Protective guard
(16) Button for mitre/bevel angle -1°
(17) Wing bolt for mitre/bevel angle preselection
(18) Chip ejector
(19) Handle (insulated gripping surface)
(20) Clamping bolt
(21) Clamping flange
(22) Circular saw blade
a)
(23) Mounting flange
(24) Speed preselection thumbwheel
(25) Spindle lock button
(26) Saw spindle
(27) Slider for preselecting the cutting depth
(28) Pair of screw clamps
a)
(29) Guide rail
a)
(30) Connector
a)
(31) Extraction hose
a)
(32) 0° cut mark
(33) 45° cut mark
(34) Plastic insert for base plate
(35) Knurled screw for guide groove clearance setting
a) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical data
Hand-held circular saw
Article number
Rated power input
No-load speed
a)
GKT 55 GCE
3 601 F75 0..
W
1400
min
-1
3600–6250
Bosch Power Tools
