EN
•
Short-circuit
•
Over temperature
3.10
Accessories Pentheon system
/i
Description
Battery pack
Battery charger
Mains connector
On-tool charge cable
Daisy chain power cable
4
Preparation for first use
4.1
General
•
Examine the equipment for completeness and damage. Do not use the equipment if it is damaged;
in that case contact the Holmatro dealer.
•
Examine the operation of the deadman's handle. when released, the deadman's handle must return
to the neutral position.
•
Before first use, charge the battery pack fully. Refer to section 5.2.
•
Put the battery pack in the battery pack fitting / adapter fitting until the battery pack locks.
•
Examine the battery pack to make sure that the lock mechanism operates correctly.
5
Operation
5.1
System operation
In a battery tool the hydraulic pump is integrated. An electric motor operates the hydraulic pump. The
electric motor is energized by a battery pack or from an external electric power source. This pump
displaces hydraulic oil and can build up pressure. The hydraulic pump is connected directly to the
hydraulic cylinder.
The hydraulic cylinder contains a plunger that can move axially. If the cylinder is filled with oil from the
bottom, the piston moves out. If the cylinder is filled from the top, the piston moves in. The direction in
which the piston moves is controlled by the so-called deadman's handle. The deadman's handle can be
rotated by the user to control the movement. If the deadman's handle is released, it returns
automatically to the neutral position and stops the movement of the tool.
In tools like cutters, spreaders and combi tools the movement of the piston drives a mechanism to make
a cutting or spreading movement.
42
model
plug type
PBPA287
PBCH1
AC-EU
PBCH2
AC-US
PBCH3
DC worldwide
PBCH4
AC-JP
PBCH5
AC-UK
PMC1
EU
PMC2
US
PMC4
JP
PMC5
UK
POTC1
worldwide
DCPC1
worldwide
916.400.096_003
151.000.583
151.000.629
151.000.742
151.000.632
151.000.630
151.000.631
151.000.633
151.000.743
151.000.634
151.000.635
151.000.499
151.000.503
PCU50
