Parts list – List of spare parts
ET 6 order No. 9107, 9108
Technical data:
Issue: 01. 02. 2009
Ergometer of Class HA / EN 957-1/ 5 with high accuracy
Motor- and Computer-controlled magnetic resistance
Approx 9 kg fl ywheel
11 stored training programs
5 stored heart frequency training programs
5 individual programs, 16 manually adjustable load steps
1 Body fat program
1 speed independent program (40 – 400 Watt, resistance adjustable in 10 Watt steps)
Hand pulse measurement
Horizontally and vertically adjustable saddle (quick release)
Saddle and handlebar inclination adjustable
Floor level compensation
Transport rollers at front foot
Power plug (Adapter)
Blue / Green Back Light LCD Display with, speed, distance, time, approx calorie consumption, pedal revolu-
tions per minute, pulse frequency and Watt.
Input of limits for time, speed and approx calories
Announcement of higher limits
Fitness – Test
Load max. 150 kg (Body weight)
Space requirement approx L 96 x W 52 x H 140 cm
Illustration
Designation
No.
1
Main frame
2
Front foot
3
Front foot cover L&R
4
Carriage bolt
5
Washer
6
Spring washer
7
Cap nut
8
Rear foot
9
Rear foot Cover
10
Allen head screw
11
Left chain cover
12
Right chain cover
13
Handlebar post
14
Computer upper cable
15
Computer lower cable
16
Saddle post
17
Plastic collar
18
Movable seat post
19
Saddle
19a
Saddle holder
20
Star grip nut
21
Seat knob
22
Computer
23
Screw
24
Hand pulse wire
25
Foam Grip
26
Pulse grip unit
27
Handlebar
28
Back handlebar cover
29
Front handlebar cover
30
Screw
31
Screw
32
Handlebar screw
33 L
Pedal left
33 R
Pedal right
34
Cross frame right
35
Adaptor
36
Screw
37
Screw
38
Turning plate cover
Please check after opening the packing that all the parts shown in
the following parts lists are there. Once you are sure that this is the
case, you can start assembly.
Please contact us if any components are defective or missing, or if
you need any spare parts or replacements in future:
Adresse:
Top-Sports Gilles GmbH
Friedrichstr. 55
42551 Velbert
Telefon: +49 (0) 20 51 - 6 06 70
Telefax: +49 (0) 20 51 - 6 06 74 4
e-mail: info@christopeit-sport.com
www.christopeit-sport.com
Dimensions
Quantity
mm
1
1
2
M8 x 52
2
8//16
12
for M8
14
M8
2
1
2
M 8 x 15
10
1
1
1
1
1
1
1
1
1
1
1
1
1
M 5 x 12
4
1
2
2
1
1
1
M 5 x 20
2
M 4 x 15
2
1
1
1
1
6VoltDC/500mA
1
M 4 x 25
5
M 4 x 30
1
2
17
Attached to
ET number
illustration No.
33-9107-01-SI
1
33-9805-02-SI
2
36-9805-07-BT
1,2
39-10448-CR
4,10
39-10018-CR
4,10,68
39-9864-CR
4
39-9900-CR
1
33-9805-03-SI
8
36-9805-08-BT
1
39-9888-CR
1+12
Black= 36-9107-01-BT
Red =
36-9108-01-BT
1+11
Black= 36-9107-02-BT
Red =
36-9108-02-BT
1
33-9107-02-SI
15,22
36-9107-04-BT
14,48
36-9107-05-BT
1,18
33-9805-05-SI
16
36-9805-11-BT
16
33-9814-05-SI
19a
36-9107-06-BT
18
36-9814-12-BT
44
36-9814-14-BT
1
36-9805-13-BT
13
black= 36-9107-03-BT
Red =
36-9108-03-BT
22
39-9988
22
36-9107-07-BT
27
36-9805-15-BT
27
36-9107-08-BT
13
33-9805-06-SI
13,29
36-9107-09-BT
13,28
36-9107-10-BT
13,28,29
39-10165
28,29
36-9805-41-BT
13
36-9805-19-BT
88
36-9805-20-BT
34
36-9805-21-BT
65
33-9805-07-SI
50
36-9107-22-BT
1,11,12
36-9805-42-BT
11,12
36-9805-43-BT
89,90
36-9107-11-BT
