4.3
Installing the charging station
1 CAUTION!
Do not place the charging station within 120 cm/4 feet of a stairwell.
•
To place the charging station in the required area:
1. Place the charging station on a hard level surface, against a wall or
other immovable object to prevent it from sliding.
2. Make sure the robot has a clear path for return at the end of a cleaning
cycle.
3. If possible, fix the charging station to the wall, by following the next
steps:
• Ensure the wall is hard, smooth, clean and dust-free to ensure a
secure fix.
• Peel off the protective film from the rear.
• Press the charging station against the wall.
Note: the adhesive tape is removable and can be reused.
4. Connect the charging station to the mains, see Figure 7. The charging
station will show a solid blue power light. Figure 8 shows an example of
a possible floorplan.
42
XEasy_UM_00-NL-EN-DE-FR-ES-IT-SV-NO-DA_v01-00.indb 42
Figure 7 - Connecting the charging station to the mains
Figure 8 - Example of placement of the charging station
