Name of each part and its function
Unit display section
Unit ON/OFF button
This button can be used for turning on/off the unit when re-
mote control is not available.
Page 6
Remote control signal receiver
3D AUTO light (green)
Illuminates during 3D AUTO operation.
HI POWER light (green)
Illuminates during HIGH POWER operation.
Accessories
Wireless remote
Wireless remote control
control holder
• Do not touch the air inlet panel while it is operating.
The air inlet panel opens up while the system is operating.
Please do not install the unit in a fashion in which the air inlet
panel cannot open or place objects near the indoor unit.
NOTE
•
Buzzer sound for remote control
When preset temperature 24°C, automatic operation and automatic airflow are selected, the buzzer sound (PiPi) is produced.
When turning off the air conditioner by pressing ON/OFF button (except CLEAN mode), the buzzer sound (Pi) is produced.
This function is useful for operating the air conditioner in the darkness.
Air flow setting
All manuals and user guides at all-guides.com
Allergen clear filter
(Light orange)
Photocatalytic washable
deodorizing filter (Orange)
CAUTION
Preset temperature
– 5 –
RUN (HOT KEEP) light (green/blue)
• Illuminates during operation.
green : except ECONO operation
blue : ECONO operation
• Blinks when airflow stops due to the 'HOT
KEEP', 'CLEAN operation'and 'operation
mode invalid'.
1.5 sec.
ON
HOT KEEP
OFF
ON
CLEAN
operation
OFF
0.5 sec.
ON
Operation
mode
OFF
invalid
TIMER light (yellow)
Illuminates during TIMER operation.
Battery
(R03 (AAA, Micro) ×2)
Wood screw (Quantity:2)
(for remote control holder mounting)
0.5 sec.
3 sec.
1 sec.
Page 22
0.5 sec.
