Controls
Figure A
1 Tab to open the water tank lid
2 Water tank lid
3 Water tank
4 Steam control knob
5 Water level gauge
6 Steam nozzle with cover
7 Drip tray
8 Drip tray compartment
9 Drip tray grid
10 ON / OFF push button
11 PUMP / STANDBY push button
12 STEAM / ESPRESSO push button
13 Status indicator lamp
14 Heater indicator lamp
15 Warming plate / cup tray
16 Filter insert for 1 cup
17 Filter insert for 2 cups
18 Filter holder
19 Filter safeguard
20 Measuring spoon / tamper / spanner
(1 part, 3 functions)
Instructions
Placement
• Place the appliance on a stable and level
surface.
• Due to rising heat and vapours do not operate
the appliance under wall cabinets.
• Do not place the appliance in close proximity to
a gas or electric stove or any other heat source.
Push Buttons (10/11/12)
These push buttons have the following functions
when locked in place or disengaged:
Switch
Engaged
10
ON
11
PUMP
12
STEAM
58
All manuals and user guides at all-guides.com
Electric Connection
1. Ensure that your mains power corresponds
2. Check the push button settings! Push buttons
3. Connect the mains cable to a properly installed
On / Off
• Engage push button (10) in ON position to
• The Indicator lamp
• Disengage push button (10) in OFF position to
Attach / Detach Filter Holder
• Hold the handle at the left edge of the appli-
• Pull the filter holder to the left to detach from the
Disengaged
OFF
STANDBY
ESPRESSO
with the specifications of the appliance. The
specifications are printed on the type label.
(10/11/12) must be disengaged.
and earthed 230 V~, 50 Hz wall outlet.
switch the appliance on. The status indicator
lamp
lights up. The appliance starts heating
up. The warming plate (15) heats up.
lights up as soon as
the necessary brewing temperature is reached.
NOTE:
The indicator lamp
turns on and off
during operation. This is normal and indicates
that the temperature is thermostat-controlled
and maintained.
switch the appliance off.
Operation
ance to attach the filter holder (see Fig. B on
page 3). Insert the three guide tabs in the group
head recesses. With the handle pull the filter
holder to the right hand side to the middle of the
appliance. Ensure that the filter holder is well
secured in the group head.
group head.
WARNING: Danger of burns!
After brewing the metal parts of filter holder
and filter insert are hot.
