REMOTE CONTROL (ONLY FOR MEDIAPLAYER)
1.
Press this button to turn the power on/off
2. MODE
Press this button to change between different modes
3. REC
Press this button to start/stop recording
4. REP
Press this button to repeat the recording
5. Vol +/-
Press this button to decrease/increase volume
6.
Press this button to start/resume or pause play
7. I / I
Press this button for Previous/Next track
8. RPT
Press this button to repeat a single music track or repeat all
9. EQ
Press this button to change for a different preset equalizer
10. Num pad
Numbers keypad selection
OPERATIONS INSTRUCTIONS
Make sure the volume control is minimal. Plug one end of the AC cord provided into the AC input jack on rear side of the
portable sound system. Then plug the other end of AC cord into AC power outlet. Turn on the unit using the main power switch
Rechargeable Battery
This unit can be powered internally using the built-in rechargeable battery. When AC power is connected, CHARGE LED
indicator will light red. The rechargeable battery is being charged. If FULL LED indicator light green, the battery is fully charged
and ready to power the unit alone.
Turn off the power switch and disconnect the AC power. Turn the unit back "ON" and the rechargeable battery will power the
unit alone.
Note: Turning off the unit power switch will allow the battery to be charged more quickly.
ATTENTION:
Before the device the first time is actuated, please charge the battery at least 12 hours and max. 72 hours!
Battery should be regularly charged. For optimal battery life the battery should be charged at least 1x per month.
Please note that if you do not load within 6 weeks, the battery becomes defective
UHF WIRELESS MICROPHONE
Insert the batteries into the wireless microphones (observe the polarity) and turn all volume controls down. Switch the system to
'ON' and the power led will light. Switch the microphone to 'ON' and set the volume knobs to the desired position.
Take care not to incur feedback from the speaker. Turn the Echo and equalizer to a position in order to have the desired sound.
BT CONNECTION
1. Activate the BT on your device (Mobile phone, tablet etc.) from which you want to play the music.
2. See the operating instructions for that device.
3. Press the [MODE] button and activate the BT-function.
4. Select " Fenton – FT12LED" on your BT device and pair
5. Press and hold the [MODE] button to disconnect the BT
Attention: BT distance is approx. 10 meter without any barrier.
LINK/STEREO (TWS) PAIRING FUNCTION
When having two Fenton – FT12LED speaker systems, it's possible to initiate a link (pairing) between the two. Both portable
systems will be emitting the same signal from the streaming audio function. To set up this stereo pairing, please follow the below
steps:
1. Turn on the power on both "Fenton – FT12LED" speaker systems
2. Change the operating mode to BT streaming on both "Fenton – FT12LED" speaker systems
3. Press and hold [
] on any speaker to pair with another speaker to connect. The speaker will give a sound when connection
is completed.
4. Press and hold [
] to disconnect.
5
