Gallagher W- Weigh Scale User Manual
INSTALLATION
Installing the W-0
The W-0 can be placed on a table top or mounted
on the bracket supplied.
Installing the Scale bracket
The bracket can be mounted on a fl at ver cal surface, a round post, or a rail.
To mount the bracket on a fl at ver cal surface, or a round wooden post, use
the 3 x tek screws included with the unit.
Important:
It is not recommended to mount the W-0 bracket on the weighing crate or
chute as interac on with the scale can impair weighing performance.
To mount the bracket on either a ver cal or
horizontal bar, use the 'U' bolts included with
the unit.
5
