All manuals and user guides at all-guides.com CONTENIDO 1. Precauciones de seguridad 2. Elementos embalados con la unidad 2.1 elementos embalados con la unidad (para los modelos SC41xx & SC5xxx) 2.2 elementos embalados con la unidad (para los modelos S41xx & S5xxx) 3.
All manuals and user guides at all-guides.com PRECAUCIONES DE SEGURIDAD Cuestiones a tener en cuenta por razones de seguridad: • Asegúrese de leer las siguientes ADVERTENCIAS antes de la instalación del aire acondicionado. • Asegúrese de tener en cuenta las precauciones especificas que incluyen elementos importantes relativos a seguridad.
All manuals and user guides at all-guides.com PRECAUCIONES • Este equipo debe estar conectado a tierra. Podría producirse descarga eléctrica si la conexión a tierra no es perfecta. No utilice un cable de extensión. De lo contrario podría provocar un incendio o descarga.
All manuals and user guides at all-guides.com 15 cm o más Kit inteligente inalámbrico Control remoto Salida de aire Tornillo de montaje B ST2.9x10-C-H Soporte del control remoto Enrolle el cable conector Figura 1 ATENCIÓN Esta ilustración es solo para propósitos de indicación y explicación. Esta ilustración podría ser diferente del aire acondicionado que ha adquirido.
All manuals and user guides at all-guides.com Doble la tubería del refrigerante en la parte trasera de la unidad con mucho cuidado. La tubería es de cobre. Al doblar la parte destacada más de una vez podría hacer que el cobre se agriete debido al proceso físico.
All manuals and user guides at all-guides.com CONSEJO La tubería, el cable y la manguera de condensación pueden conectarse fácilmente tirando de la parte inferior de la unidad interior a unos 5 cm de la pared e insertando algo temporalmente para que el hueco permanezca abierto, consulte la figura 3. Conecte las tuberías de refrigerante, los cables eléctricos y la manguera de condensación a la unidad interior.
All manuals and user guides at all-guides.com ATENCIÓN Para los modelos SC41xx & SC5xxx: La longitud de la tubería es de 4 metros. Para los modelos S41xx & S5xxx: Para unidades con una capacidad superior a 6.0 kW, la longitud máxima de la tubería entre la parte interior y la exterior es de 20 metros.
Pagina 10
All manuals and user guides at all-guides.com Más de 30cm. Más de 60cm. Más de 30cm. Valla o barrera Más de 60cm. Figura 5 Más de 200cm. • Al determinar la ubicación de la unidad exterior tenga en cuenta la posible localización de la unidad interior.
All manuals and user guides at all-guides.com ATENCIÓN Si fuera necesario suspenda la instalación, el soporte de montaje debe concordar con todos los requisitos técnicos. La pared de la instalación debe ser lo bastante fuerte o adopte acciones para reforzarla. En cuanto a la conexión entre el soporte y la pared, el aire acondicionado y el soporte deben estar bien firmes, estables y seguros.
All manuals and user guides at all-guides.com MONTAJE DE LA PLACA DE INSTALACIÓN Y HACER QUE LA TUBERÍA PASE A TRAVÉS. 7.1 Montaje de la placa de instalación de la unidad interior. ¡ADVERTENCIA! Use un detector de tuberías para buscar conductos eléctricos en la pared antes de taladrar los orificios necesarios y evitar daños innecesarios o situaciones peligrosas.
All manuals and user guides at all-guides.com S(C)5x32/SC4132 452.7mm Indoor unit outline 406.4mm 249mm pipe hole pipe hole 65mm 65mm 102mm 153mm 805mm S(C)5x48/SC4148 Perforación de la tubería, la manguera de condensación y el cable de alimentación. Determine las posiciones de los orificios de acuerdo con el esquema detallado en la Fig. 9. Taladre un (1) orificio (≥...
All manuals and user guides at all-guides.com Pared Exterior Interior ≥5° Figura 10 CONEXIÓN DE LOS TUBOS DE REFRIGERANTE Conexión y desconexión de los tubos de refrigerante para los modelos SC41xx & SC5xxx. ADVERTENCIA La conexión de las tuberías de refrigerante del aire acondicionado debe realizarse de acuerdo con la normativa y legislación nacional vigente.
All manuals and user guides at all-guides.com ≥ ø85 mm Los últimos 20 cm del tubo refrigerante próximos al conector deber estar rectos. La curvatura puede causar fugas que no están cubiertas por la garantía. < 20 < 20 ≥ 20 ≥...
All manuals and user guides at all-guides.com PRECAUCIÓN • Asegúrese de que la manguera de drenaje está en el lado inferior del grupo. Colocarlo en el lado superior puede causar el desbordamiento de la bandeja al interior de la unidad. •...
All manuals and user guides at all-guides.com 11. CONEXIÓN DE LOS CABLES ELÉCTRICOS. 11.1 Conexión de los cables eléctricos para los modelos SC41xx & SC5Xxx. El cable de 4,5 metros para la conexión eléctrica entre la unidad exterior y la interior está incluido en el embalaje de la tubería de refrigerante (unidad interior).
Pagina 19
All manuals and user guides at all-guides.com Para el montaje del cable a la unidad interior: Retire el panel delantero y la placa de cubierta de la regleta de terminales el el lado derecho de la unidad interior. Figura 19. Front Panel Panel frontal Electronic box...
All manuals and user guides at all-guides.com 12. EVACUACIÓN DEL SISTEMA DE REFRIGERACIÓN PARA LOS MODELOS S41XX & S5XXX. El aire y humedad que permanecen en el sistema de refrigerante, p.ej. después de la instalación, podría causar daños o efectos no deseados como se indica abajo: •...
All manuals and user guides at all-guides.com Para tuberías superi- ores a 5 metros Modelo Llenado extra por metro en gramos 2,5 – 2,6 kW 3,1 – 3,6 kW 4,8 – 5,4 kW Tabla 2 Use solo refrigerante del mismo tipo que se indica en la placa de tipo. 15.
Pagina 22
