Dremel 3D20 Vertaling Van De Originele Gebruiksaanwijzing pagina 4
Beschikbare talen
Beschikbare talen
FUNCTIONAL DESCRIPTION AND
SPECIFICATIONS
BUILDING
Extruder: Single extrusion
Extruder temperature: Up to 230°C (397°F)
Operating Interface: 3.5" full colour IPS touch screen
Maximum Build Volume: 9" x 5.9" x 5.5"
(230mm x 150mm x 140mm)
Layer Thickness: 4 mil | 0.004 inches 100 microns |
0.10 mm
Filament colours: See Dremel3D.com for colour
choices
SD Card: Up to 32GB in size (3D20 will not work with
SD cards larger than 32GB)
Internal Storage: 4GB
WEIGHT & DIMENSIONS
Weight (without spool): 8.8kg (19lbs 8oz)
Dimensions: 19.1" x 15.7" x 13.2" (485mm x 400mm
x 335mm)
FILAMENT
ONLY works with Dremel PLA filament
Filament: 1.75mm PLA
(Biodegradable/Renewable)
FILAMENT STORAGE
All polymers degrade with time. Do not unpack until
filament is needed. Filament should be stored at room
temperature: 16-29° C (60-85° F)
SOFTWARE
Dremel 3D20 comes with complimentary Dremel 3D
software for Windows and Mac OSX. This application
converts your 3D digital files into buildable files.
All manuals and user guides at all-guides.com
A PC with these minimum requirements will be required
to run the Dremel
Processor: Multi-core processor - 2 GHz or faster per
core
System RAM: 2 GB
Screen Resolution: 1024x768
USB port
Dremel
Systems
Windows Vista or later
Dremel
3D20 input rating: 220-240V~, 50/60Hz, 0.65A
Room Temperature: 16-29° C (60 - 85° F)
Level workspace
Dry workspace environment
4
MINIMUM HARDWARE REQUIREMENTS
3D Software
®
WINDOWS REQUIREMENTS
Software runs on 32 and 64-bit Operating
®
MAC OSX REQUIREMENTS
Software runs on Mac OSX 10.8 or later
®
ELECTRICAL REQUIREMENTS
OPERATING ENVIRONMENT
19.1" (485mm)
WALL
8" (203mm)
13.2" (335mm)
8" (203mm)
