Fluval PLANT PRO LED Instructiehandleiding pagina 3
DIMMABLE LED WITH ILLUMINATED TOUCH SWITCH CONTROL:
Illuminated Touch Switch: Switch changes color to indicate the different settings: off
(red illumination), all lights on (white illumination), Blue lights only (blue illumination), Bluetooth mode
(green illumination).
Dimming Feature: Lighting intensity can be dimmed on both the white illumination setting (all lights
on)or the blue illumination setting (only blue lights on) by depressing the switch and keeping finger
on it until preferred lighting intensity is reached. NOTE: Once dimming intensity level is chosen it will
remain fixed at that level, even if fixture is turned off. To change the intensity level it is necessary to
manually depress and hold down the switch.
MAINTENANCE:
For maximum LED performance, it is recommended that the fixture and the LED lens be cleaned on a
weekly basis. Unplug transformer prior to cleaning the light fixture and remove from aquarium. Use
both hands when manipulating this appliance. Wipe exposed surfaces carefully with a damp cloth
to remove any dust or mineral deposits that may collect over time. Do not use detergents or harsh
cleaners as it can damage the light fixture. Make sure all surfaces are dry before re-connecting the
transformer to the power source.
BASIC TROUBLE-SHOOTING:
If the fixture does not work, ensure that all plugs and wires are firmly connected, ie: connection from
fixture to transformer, and connection from transformer to electrical outlet.
Model
16895
Input Volts
100-240 V
Operating Volts
24 V
Size
15 - 23.5"
Adjustment
38 - 60 cm
No. of LEDs
198
Wattage
38
Lumens
3000
Life in Hours
50 000
FOR AUTHORIZED WARRANTY REPAIR SERVICE:
QUESTIONS? If you have a problem or question about the operation of this product, please let us try
to help you before you return the product to your dealer. Most problems can be handled promptly
with a phone call. Or, if you prefer, you can contact us on our web site at www.fluvalaquatics.com.
When you call (or write), please have all relevant information, such as model number and/or part
numbers available.
CANADA: Consumer Repair, Rolf C. Hagen Inc., 20500 Trans Canada Hwy,
Baie d'Urfé, QC H9X 0A2
U.S.A.: Rolf C. Hagen (U.S.A.) Corp., 305 Forbes Blvd, Mansfield, MA. 02048
UK: Rolf C. Hagen (UK) Ltd, Customer Service Department California Drive, Whitwood Ind Est.,
Castleford West Yorkshire WF10 5QH
CALL US ON OUR TOLL-FREE NUMBER:
CANADA ONLY: 1-800-554-2436 between 8:00 am and 4:30 p.m. Eastern Standard Time.
Ask for Customer Service.
U.S. ONLY: 1-800-724-2436 between 9:00 a.m. and 4:00 p.m. Eastern Standard Time.
Ask for Customer Service.
U.K. ONLY: Helpline Number 01977 521015. Between 9:00 AM and 5:00 PM, Monday to Thursday and
9:00 AM and 4:00 PM on Friday (excluding Bank Holidays).
RECYCLING:
This symbol bears the selective sorting symbol for waste electrical and electronic
equipment (WEEE). This means that this product must be handled pursuant to European
Directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the
environment. Check with your local Environmental Agency for possible disposal instructions
or take to an official council registered refuse collection point. Electronic products not
included in the selective sorting process are potentially dangerous for the environment and human
health due to the presence of hazardous substances.
WARRANTY
2 YEAR LIMITED WARRANTY
Your Fluval Plant PRO LED is guaranteed for defective parts and workmanship for a period of 2 years
from the date of purchase. This guarantee is valid with proof of purchase only. The guarantee is limited
to repair or replacement only and does not cover consequential loss, loss or damage to livestock and
personal property or damage to animate or inanimate objects, irrespective of the cause thereof. This
guarantee is valid only under normal operating conditions for which the unit is intended. It excludes
any damage caused by unreasonable use, negligence, improper installation, tampering, abuse or
commercial use. The warranty does not cover wear and tear or parts which have not been adequately
or correctly maintained. Failure of less than 5% of the total number of LEDs shall not be considered a
defect under the terms of this warranty. THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
RED= OFF
WHITE= ON
BLUE= BLUE ONLY
GREEN= BLUETOOTH MODE
16896
16897
100-240 V
100-240 V
24 V
24 V
23.25 - 34"
35 - 48.25"
59 - 88 cm
88 - 124 cm
336
504
60
90
4800
7200
50 000
50 000
SUSPENSION KIT
MOUNTING OPTION:
SCAN FOR SET UP
INSTRUCTIONS
16898
100-240 V
24 V
46.25 - 60.5"
117 - 154 cm
672
120
9600
50 000
