troubleshooting

What to do in case of a malfunction? In most cases, you will be able to correct these faults easily yourself. Please check the

solutions below before contacting the Inventum service department.

The motor is not running

• Is it plugged in correctly?

• Is there a power outage?

• Check the electrical installation.

The performance of the cooker hood is not correct and makes more nois.

• Is the diameter of the exhaust-air pipe correct?

• Is the duct blocked?

• The diameter of the duct must be 150 mm. A smaller diameter can negatively influence the suction of the motor.

• Are the grease filters clean?

• Is the carbon filter not replaced within the last 6 months? Replace the carbon filter.

• Is there enough air supply to replace the extracted air?

installation

Read these installation instructions carefully before starting the installation.

Decide whether there is a duct available or if the cooker hood needs to recirculate. We advise to install the cooker hood

with two persons.

• The minimum distance between the supporting surface for the cooking pans on the cooker and the lowest part of the

hood must be:

- 55 cm for an electric, ceramic or induction cooker

- 65 cm for a gas hob

• If the cooker hood is to be fitted to an existing duct no other aplliances, such as a geyser or heater, may be connected to

that same duct.

• The shorter the duct, and the fewer the bends in it, the better the cooker hood will work.

• The connection pipe for the cooker hood has a diameter of 150 mm.

150

upper support = 274 mm

Optional:

lower support = 263,5 mm

8x36mm

4x30mm

8x36mm

4x30mm
