Dante Audio & Controller
Port
TCP/UDP
162
udp
[319-320]*
udp
2203
udp
4321, 14336-14600
udp
[4440, 4444, 4455]*
udp
5353
udp
[8700-8706, 8800]*
udp
8751
udp
16000-65536
udp
*These ports must be open on the PC or control system to access the device through a firewall.
These protocols require multicast. Ensure multicast has been correctly configured for your network.
†
Specifications
Analog Connections
Input
(2) 3-pin block connector (Active Balanced)
Output
(2) 3-pin block connector (Impedance Balanced)
Mobile
(1) TRRS 3.5 mm (1/8")
USB Connections
(1) USB 2.0, Type B
Single port carries 2 input and 2 output channels (Summed mono)
Network Connections (Dante Digital Audio)
(1) RJ45
10 Dante input channels, 2 output channels
Polarity
Non-inverting, any input to any output
Power Requirements
802.3 at Type 2 (PoE Plus), Class 4
Power Consumption
17.5 W, maximum
Weight
1710 g (3.8 lbs)
Dimensions
H x W x D
4 x 21 x 22.6 cm (1.6 x 8.3 x 8.9 in.)
control application
HTML5 Browser-based
Operating Temperature Range
−6.7°C (20°F) to 50°C (122°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
Thermal Power Dissipation
Maximum
17.5 W (60 BTU/hr)
typical
14.6 W (50 BTU/hr)
Audio
Frequency Response
+1, -1.5 dB
20 to 20,000 Hz
Dante Digital Audio
Sampling Rate
48 kHz
Bit Depth
24
All manuals and user guides at all-guides.com
Protocol
Description
SNMP
Used by Dante
PTP
Dante clocking
†
Custom
Required for packet bridge
Dante
Dante audio
Dante
Dante audio routing
mDNS
Used by Dante
†
Dante
Dante Control and Monitoring
Dante
Dante Controller
Dante
Used by Dante
USB Audio
Latency
Analog Connections (Block Connectors)
Dynamic Range
20 Hz to 20 kHz, A-weighted, typical
Equivalent Input Noise
20 Hz to 20 kHz, A-weighted, input terminated with 150Ω
Total Harmonic Distortion
@ 1 kHz, 0 dBV Input, 0 dB analog gain
Common Mode Rejection Ratio
150Ω balanced source @ 1 kHz
Input Impedance
Input Clipping Level
Output Impedance
Output Clipping Level
11
Sampling Rate
44.1, 48 kHz
Bit Depth
16, 24
Does not include Dante latency
Dante 1-8 in to Dante out (AEC enabled)
Dante 1-8 in to Dante out (AEC disabled)
Dante 9-10 in to Dante out
Analog in to Analog out
Analog-to-Dante
113 dB
Dante-to-Analog
117 dB
Line
-86 dBV
Aux
-98 dBV
<0.05%
>50 dB
9.6 kΩ
Line
+27 dBV
Aux
+15 dBV
80 Ω
Line
+20 dBV
Aux
+0 dBV
Mic
-26 dBV
12.5 ms
5.8 ms
1.8 ms
2.2 ms
