Quick guide
THANK YOU FOR BUYING OUR PRODUCT.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
CONTROL PANEL
1.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance off. In
Stand-by mode the light in the refrigerator compartment does not turn
on. Press the button again briefly to reactivate the appliance.
Note: this does not disconnect the appliance from the power supply.
FREEZER AND REFRIGERATOR
COMPARTMENT TEMPERATURE
The three LED indicators indicate the refrigerator compartment
set temperature. It is possible to set a different temperature of the
appliance with the
button.
The following adjustments are possible:
LEDs lit
Recommended setting:
•
Refrigerator compartment: MEDIUM
To avoid food waste, please refer to the recommended setting and storage
times found in the online user manual.
* Available only on certain models
24-Apr-2024 11:41:57 CEST | RELEASED
2.
3.
Set temperature
High (less cold)
Medium-high
Medium
Medium-low
Low (colder)
In some European factories the letter "W" of the part code mentioned herein will be automatically
Before using the appliance carefully read the Safety Instruction.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally filled
appliance. Position the antibacterial anti-odour filter in the fan as
demonstrated in the filter packaging (if available). If the audible signal
sounds, it means that the temperature alarm has intervened: press the
button to switch off the acoustic alarms.
1.
2.
3.
FAN*
You can turn the Fan on/off by pressing the button on the base (as
shown in the figure). If the ambient temperature exceeds
27°C, or if drops of water are present on the glass shelves,
it is essential that the fan is on to ensure the proper
preservation of the food. Deactivation of the fan allows
energy consumption to be optimised.
FREEZING FRESH FOOD
Place the fresh food to be frozen in the FREEZING ZONE in the freezer
compartment avoiding the direct contact with the food that is already
frozen. To optimize the freezing speed, the lower drawer can be
removed and the food can be placed directly on the bottom of the
compartment.
FAST COOL FUNCTION (FAST COOLING)
To quickly cool the refrigerator compartment, or
24 hours before putting a large quantity of food
to be frozen in the freezer compartment, turn
on the "Fast Cooling" function by repeatedly
button until the 3 icons flash
pressing the
green and then stay constant.
The function automatically turns off after 50 hours and the
temperature returns to the previous setting when the function is
turned on.
To turn the function off manually, press the button.
Note: avoid a direct contact between the fresh food and the food that is
already frozen.
To optimize the freezing speed, the lower drawer can be removed and
the food can be placed directly on the bottom of the compartment.
replaced by the number "4000" (e.g. "W12345678" becomes "400012345678")
LED Light
On/Stand-by
Freezer and refrigerator compartment
temperature button
EN
