Specifications
System
Frequency range
Transmission system
Audio codec
Dynamic range
Latency
Total harmonic distortion
(THD)
Encryption
Temperature
Relative air humidity
Dripping and splashing
liquids
EM 6000, EM 6000 DANTE
Receiving channels
Receiver principle
Diversity
Frequency range
Sensitivity
Image rejection
Blocking
Audio frequency response
Analog audio outputs
Digital audio outputs
Headphone output
Antenna inputs
Daisy chain outputs
Daisy-chained receivers (RF)
Booster supply voltage
Word clock input
Word clock output
470 - 714 MHz
Digital modulation,
Long Range Mode (LR):
Min. frequency spacing for equidistant grid: 400 kHz
Link Density Mode (LD):
Min. frequency spacing for equidistant grid: 200 kHz
LR Mode: SeDAC (Sennheiser Digital Audio Codec)
LD Mode: SePAC (Sennheiser Performance Audio Codec)
111 dB (A) typ.
Analog audio out:
3 ms (LR) / 3.2 ms (LD)
Digital audio out:
3 ms (LR) / 3.2 ms (LD) (AES/EBU)
< 0.03 % (@ 1 k Hz)
AES 256
Operation:
-10°C to +50°C
Storage:
-25°C to +70°C
Operation:
Max. 85% at 40°C (non-condensing)
Storage:
Max. 90% at 40°C (non-condensing)
The product must not be exposed to dripping and splashing (IP2X)
2
Double superheterodyne
True bit diversity
470 - 714 MHz
-100 dBm typ.
> 100 dB typ.
> 80 dB typ.
LR Mode: 30 Hz - 20 kHz (1.5 dB)
LR Mode: 30 Hz - 14 kHz (1.5 dB)
XLR-3 and 6.3 m m jack per channel (transformer balance),
-10 dBu to +18 dBu in steps of 1 dB (2 kΩ)
AES3-2003, XLR-3:
48 kHz, 96 kHz, 24 bit
Dante™, RJ-45:
48 kHz, 96 kHz, 24 bit
Can be externally synchronized using WCLK loop-through with BNC sockets
6.3 mm jack, 2x 100 mW at 32 Ω
2x BNC (50 Ω)
2x BNC (50 Ω)
0 dB +/- 0.5 dB amplification relative to antenna inputs
Max. 8 EM 6000 units
12 V 3, max. 200 mA each via antenna sockets, short circuit proof
BNC, 75 Ω
BNC, 75 Ω
Digital 6000 | 7
