B - prOduCT dESCripTiON
3 - INTELLIGENT bRACKET
1
Monitor connection terminal
Connection terminals
2
Indicator light for connecting an additional
3
monitor
:
R ed = Connection error
B lue = Connection OK or monitor not present
4
Power supply indicator light
R ed = Power supply > 16V
Blue = Power supply < 16V OK
4 - INTERCOM PANEL
front view
1
2
3
1
Wall mount for the intercom panel
Infra-red LED
2
Name label
3
Microphone
4
Camera lens
5
6
EN
All manuals and user guides at all-guides.com
:
4
5
6
7
Colour video interCom 18Cm
1
2
3
4
4
5
2
Intercom panel connection indicator ligh t :
5
Red = Reverse polarity
Blue = Wiring OK
6
Intercom panel connection indicator light
Red = intercom panel not connected (wire
unplugged or cut)*
Blue = connection OK
* This is completely normal if the monitor is
used as an additional monitor on an existing
installation and no intercom panel is directly
connected to it
8
6
Loudspeaker
Call button
7
Camera position adjustment screw
8
Connection terminal block
9
Screw hole for attaching the intercom panel
10
to the wall mount
1
3
6
front view
10
:
9
