POWER
HDCC90011 | HDCC90021
On and off device switch
AUDIO IN
Cinch inputs
Video OUT
Alarm In/Out
GND
VIDEO IN
12 V DC
BNC input for
Connection for power supply
USB
HD-TVI and analog
Connection for USB devices
RS-485
cameras
Connection for PTZ cameras
HDCC90011
8 BNC inputs
LAN
HDMI
HDCC90021
RJ45 port for a network
HDMI monitor connection
16 BNC inputs
connection
AUDIO OUT
VGA
Cinch audio output (synchronised
VGA monitor connection (9-pin),
with main video signal output)
video output signal
