˜ Intended use
This product is designed for applying paint,
lacquers, and glazes.
You can use the product to process
spray material with a flow time of up to
max. 70 DIN/sec.
The product is not permitted to be used
with easily flammable, combustible paints,
lacquers or thinners.
Always use the spray materials according
to the intended use! Observe the
technical requirements of this product
(see "Technical data") when purchasing and
using accessory spray materials!
Any other use or modification of the product
are considered improper use and can result
in hazards such as death, life-threatening
injuries and damage. The manufacturer
is not liable for any damages caused by
improper use. The product is not intended
for commercial use or for any other use.
˜ Scope of delivery
WARNING!
m
The product and the packaging
u
materials are not children's toys!
Children must not play with plastic
bags, sheets and small parts! There is
a danger of choking and suffocation!
1× HVLP Paint spray gun
4× Nozzle*:
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
1× Viscosity measuring cup
1× Cleaning needle
1× Cleaning brush
2× Filter**
1× Operating instructions
* 1 nozzle is pre-installed
** 1 filter is pre‑installed
˜ Parts description
Figure A:
Nozzle, 4×
1 ]
[
Ø 1.5 mm
Ø 1.8 mm
Ø 2.2 mm
Ø 2.6 mm
Needle
2 ]
[
Small thread
3 ]
[
Spray unit
4 ]
[
Align spray unit
[
5 ]
Connecting tube
[
6 ]
Trigger
[
7 ]
Adjusting wheel
8 ]
[
Paint container
[
9 ]
Riser tube
[
]
Large thread
[
]
Union nut
[
]
Nozzle head
[
]
Figure B:
Motor unit
[
]
Air filter
[
]
Release button
[
]
Air filter cover
[
]
Power cord with power plug
[
]
Spare air filter
[
]
Measuring cup
[
]
Cleaning needle
[
]
Cleaning brush
[
]
Handle
[
]
Lock
[
]
Spray connection
[
]
Unlocked
[
]
Locked
[
]
˜ Technical data
Rated power
Rated voltage
Delivery rate
Paint container
Max. viscosity
Protection class
450 W
230 V~ 50 Hz
950 ml/min (water)
1200 ml
70 DIN/sec
II/
GB/IE/NI
