Passieve veldbox
4.6 Aansluitvoorbeeld
Safety IN 1
Veiligheids-
module
Safety IN 2
+24 VDC
Spanningsto-
evoer
0 VDC
OUT 1
OUT 2
OUT 3
OUT 4
PLC
OUT 5
OUT 6
OUT 7
OUT 8
OUT 9
6
Veilig-
heidsschakel-
componenten
WH (2)
BK (4)
10A
BN (1)
BU (3)
BN (2)
IN 1
YE (4)
IN 2
PK (6)
IN 3
RD (8)
IN 4
WH (1)
GN (3)
GY (5)
BU (7)
BN (2)
IN 5
YE (4)
IN 6
WH (1)
GN (3)
BN (2)
IN 7
YE (4)
IN 8
PK (6)
IN 9
WH (1)
GN (3)
GY (5)
1
2
1
2
O
N
I
NL
PFB-IOP-4M12-IOP
3
4
2
3
1
4
- Veldbox in het midden
SW 7 + 8 OFF
3
4
5
6
7
8
- 4 componenten aangesloten
SW 1 - 6 OFF
I/O
O
Power
