13  Technische gegevens
DC-stringaansluiting aan connector MC4
Kabeldoorsnede
Maximale nominale stroom
DC-stringaansluiting aan connector MC3
Kabeldoorsnede
Maximale nominale stroom
DC-stringaansluiting aan connector SUNCLIX
Kabeltype
Kabeldoorsnede
Kabeldiameter
Maximale nominale stroom
DC-stringaansluiting aan veerklem
Klembereik
Kabelschroefverbinding
Kabelfixatie
DC-stringaansluiting op scheidings- en meetklem
Type klem
Maximale aansluitdoorsnede
Kabelinvoer via meervoudige
schroefverbindingen
Klembereik van meervoudige
schroefverbindingen
Aardaansluiting
Type klem
Maximale aansluitdoorsnede
Kabelinvoer en kabelschroefverbinding
Klembereik van de kabelschroefverbinding
82
SSM16-24-IA-INL105120
6 mm
30 A
4 mm
20 A
PV1-F
2
2,5 mm
... 6 mm
5 mm ... 8 mm
40 A
2
0,2 mm
... 6 mm
M32
3 x 5 mm / 3 x 7 mm / 3 x 9 mm
Veerklem
2
0,2 mm
... 6 mm
M50
5,0 mm ... 5,5 mm / 5,6 mm ... 6,0 mm /
6,1 mm ... 7,0 mm / 7,1 mm ... 8,0 mm /
8,1 mm ... 9,0 mm
Insteekklem
35 mm
M25
7 mm ... 14 mm
SMA Solar Technology AG
2
2
2
2
2
2
Installatiehandleiding
