TRANSMISSIE ASSEMBLAGE (VERVOLG)
22
18
28
27
25
26
42
30
20
44
24
35
33
43
28
33
12
33
33
12
33
28
1
Item
Order
Description
No.
No.
1
644619
Pump Plate - 300
2
391462
Hydro Pump Lt.
3
391463
Hydro Pump Rt.
4
784093
Tube - Steering Linkage 321D
5
265617
Ball Joint RH Thread Male
6
254441
Nut RH Thread
7
265618
Ball Joint LH Thread Male
8
254444
Nut LH Thread
9
281562
Key
10
725338
Control Arm
11
265680
Ball Stud
12
253035
Whiz Nut
13
257020
Washer
14
603726
Roller Assembly - Eccentric
(includes items 15 & 16)
15
257410
Washer - Star
16
254450
Nut
17
253182
Whiz Bolt
18
253025
Whiz Nut
19
754128
Mount - Neutral Return Rt.
20
754129
Mount - Neutral Return Lt.
21
729136
Arm - Neutral Return Front Rt.
22
729137
Arm - Neutral Return Front Lt.
23
729138
Arm - Neutral Return Rt.
LINKS
12
10
36
12
32
11
14
15
8
7
13
31
26 27
16
18
29
17
2
9
3
9
33
28
33
12
43
4
45
11
38
40
39
37
38
31
40
39
31 37
36
31
8
10
11
12
7
32
13
34
14
16
15
18
17
43
29 27 26
23
33
41
30
33
44
44
Item
Order
No.
No.
24
729139
25
283823
26
822304
27
257030
28
243335
29
253890
30
243035
31
253043
32
253038
33
253192
34
766215
35
766216
36
285031
37
885123
38
320857
39
774020
40
254452
41
766221
42
766222
43
254431
44
253174
45
606528
54
5
6
45
4
11
RECHTS
21
12
18
28
19
25
26 27
Description
Arm - Neutral Return Lt.
Spring - Extension
Pivot Bearing - Neutral Return
Washer
Bolt
Lock Nut
Bolt
Whiz Nut
Whiz Nut
Whiz Bolt
Reinforcement Plate Rt.
Reinforcement Plate Lt.
Damper w/Ball Socket & Retainer
Hub - Fan Mount
Fan - CW
Washer
Nut
Fan Shield Rt.
Fan Shield Lt.
Speed Nut
Whiz Bolt
Steering Linkage Assembly 321D
(includes items 4-8)
6
5
11068A
11068A
