TKS
Utgave:
Redskap:
3
Issue:
Implement:
Dato:
Enhet:
08-10
Date:
Unit:
Ref.
Delenr.
Ant.
No.
Part nr.
Qty.
1
273080
1
2
273081
1
3
273082
2
4
273075
1
5
270006
2
6
270015
2
7
270005
3
8
270014
10
9
270016
2
10
911622
2
11
273078
1
12
270019
2
13
920251
4
14
265019
2
15
933007
2
16
UH868431
2
17
UH415758
4
18
921428
20
19
989009
1
20
273106
6
21
273087
1
22
273451
1
23
273079
2
24
921002
2
25
920236
1
26
273452
2
27
273070
2
28
273237
1
29
273741
1
30
273054
1
31
400542
3
32a
921471
1
32b
921473
1
33
920330
3
34
273738
3
35
911063
3
920154
6
917204
3
36
911032
3
920154
917204
37
933502
2
38
UH415758
2
39
273453
2
40
UH866455
2
MAGAZINE R2
BUNN
BOTTOM
Gjenstand:
SIDEVANG BUNN V. LANG
SIDEVANG BUNN H. LANG
TRUCKFESTE
FREMRE BJELKE
TVERRBJELKE
GLIDESKINNE BAK
KANAL BUNNVANGE
MEDBRINGER
MOTSTÅL
STRAMMEBOLT
STRAMME BJELKE
RETURAKSLING
SKIVE Ø31/Ø58-6
KABELARHJUL 10X35
KULELAGER Ø30/Ø72-19 6306 RS BALL BEARING Ø30/Ø72-19
LÅSERING UTV. AV30X1.5
ANSATS M8
SKJØTELØKKE 10mm x 45
KRYSSFINER 1075 X2580 X12 mm PLYWOOD
SIDEVANGE FORSTERKNING
DRIV AKS. KOMPL.
AKSLING DRIFT BUNNBELTE
KABELARHJUL Ø35 10X35
SEGERING A-35
STØTTERING Ø35-45-2
HYLSE
LAGERHUS
KJEDEHJUL Z28 3/4"
AKSLING DEKSEL
RETUR DEKSEL
KABELRING
KJETTING 10X35MM 17 LEDD
KJETTING 10X35MM 15 LEDD
KILE 10X8X36 M/RUNDE ENDER
PLATEVINKEL
6KT. SKRUE M10X30
BRIKKE M10/Ø21/2MM
LÅSEMUTTER M10
LÅSESKRUE M10X25
BRIKKE M10/Ø21/2MM
LÅSEMUTTER M10
KULELAGER Ø35Ø72-17 6207 1Z
ANSATS M8X1
STØTTEHYLSE
SPENNHYLSE 8X55
Fig:
Description:
BOTTOM FRAME LH LONG
BOTTOM FRAME RH LONG
BRACKET
FRONT BEAM
CROSS BEAM
GLIDE RAIL REAR
CANAL
CARRIER
COUNTERROD
TIGHTENING BOLT
TENSIONING BEAM
RETURN SHAFT
WASHER Ø31/Ø58-6
CHAIN SPROCKET WHEEL10X35
LOCK RING
FITTING M8
LINK
FRAME AMPLIFICATION
DRIVE SHAFT ASSY.
SHAFT DRIVE BOTTOM BELT
CHAIN SPROCKET WHEEL10X35
CIRCLIP A-35
WASHER Ø35-45-2
COLLAR
BALL BEARING
SPROCKET Z28 3/4"
COVER
COVER
CABLE RING
CHAIN 10X35MM 17 LINKS
CHAIN 10X35MM 15 LINKS
KEY 10X8X36 ROUND ENDS
PLATE ANGLE
HEX.BOLT M10X30
WASHER M10/D21/2MM
LOCK NUT M10
LOCK SCREW M10X25
WASHER M10/D21/2MM
LOCK NUT M10
BALL BEARING Ø35Ø72-17 6207
FITTING M8X1
COLLAR
TENSION PIN 8X55
55
55
1
Anmerkning:
1600
