Before starting up, please read this manual carefully in order to ensure the correct and safe
installation and usage. Damage caused by not following the instructions of this manual will
always invalidates the warranty.
CaterChef would like to emphasize that this instruction manual needs to be readed carefully
before usuge and should be stored for later use.
BASIC SPECIFICATIONS:
MODEL
Dimensions (cm)
688018
41,3(H)x46,5x29cm
688218
41,3(H)x46,5x58cm
For more information we would like to ask you to go to our website www.emga.com.
You could for example search on item nr. and go to downloads. Here, you will be able
to find more information like the exploded view, the spare part list and the Declaration of
Conformity (for among other things CE and Food Safety).
TYPE PLATE
information such as the voltage and power supply which determines the ability to properly
connect the device.
TRANSPORT AND STORAGE:
During transport, the product should be placed carefully. Make sure you prevent
any drastic vibration during transport. You should never place or store this
product outside or in open air for a longer period of time than a few hours
INDOOR
USE ONLY
(not even packed). This should be done in a well-ventilated warehouse without
corrosive gasses. When, in case of an emergency, you need to store them temporarily
outside, you should take measures to protect them from rain or moisture. As long as they
are packed, please make sure you never place them upside down. This could damage the
appliance.
SAFETY PRECAUTIONS AND USAGE ENVIRONMENT:
1. Remove all packaging material and any protective film from the device.
2. This product should be placed in a balanced and well ventilated spot and its left and
right sides should be free from obstacles for more than 10cm. It's back-side should be
free from the obstacles (like a brick wall etc) for more than 20cm.
3. The supply voltage of the device (230 Volt/50Hz/1Ph) must be compressed with the
voltage of the mains.
4. The user should install the suitable power switch, fuse and leakage-protector near to the
equipment.
688018-218 en-nl ma 2020
Voltage (V)
230
2x230
The type plate (the picture is an example) is located on the
side of the device. You are requested not to remove it.
The type plate can for example be used to determine,
when the item was purchased (PO) and from which
production line (SN) it originates. This information may be
essential with regard to warranty. It also contains important
Hz
Power (W)
50
3500
50
2x3500
Thermostat
0-190ºC
0-190ºC
8
