1. Er is een <CR> na
Optoma EW610ST/EX610ST RS232 Command Table.
alle ASCII com-
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
mando's.
Baud Rate : 9600
Data Bits: 8
Parity: None
2. 0D is de HEX code
Stop Bits: 1
Flow Control : None
voor <CR> in ASCII
UART16550 FIFO: Disable
code.
Projector Return (Pass): P
Projector Return (Fail): F
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to projector
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code
HEX Code
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX00 1
7E 30 30 30 30 20 31 0D
~XX00 0
7E 30 30 30 30 20 30 0D
~XX00 1 ~nnnn
7E 30 30 30 30 20 31 20 a 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX01 1
7E 30 30 30 31 20 31 0D
~XX02 1
7E 30 30 30 32 20 31 0D
~XX02 0
7E 30 30 30 32 20 30 0D
~XX03 1
7E 30 30 30 33 20 31 0D
~XX03 0
7E 30 30 30 33 20 30 0D
~XX04 1
7E 30 30 30 34 20 31 0D
~XX04 0
7E 30 30 30 34 20 30 0D
~XX05 1
7E 30 30 30 35 20 31 0D
~XX06 1
7E 30 30 30 36 20 31 0D
~XX07 1
7E 30 30 30 37 20 31 0D
~XX08 1
7E 30 30 30 38 20 31 0D
~XX09 1
7E 30 30 30 39 20 31 0D
~XX10 1
7E 30 30 31 30 20 31 0D
~XX12 1
7E 30 30 31 32 20 31 0D
~XX12 5
7E 30 30 31 32 20 35 0D
~XX12 6
7E 30 30 31 32 20 36 0D
~XX12 9
7E 30 30 31 32 20 39 0D
~XX12 10
7E 30 30 31 32 20 31 30 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX20 1
7E 30 30 32 30 20 31 0D
~XX20 2
7E 30 30 32 30 20 32 0D
~XX20 3
7E 30 30 32 30 20 33 0D
~XX20 4
7E 30 30 32 30 20 34 0D
~XX20 5
7E 30 30 32 30 20 35 0D
~XX20 7
7E 30 30 32 30 20 37 0D
~XX20 8
7E 30 30 32 30 20 38 0D
~XX20 9
7E 30 30 32 30 20 39 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX21 n
7E 30 30 32 31 20 a 0D
~XX22 n
7E 30 30 32 32 20 a 0D
~XX23 n
7E 30 30 32 33 20 a 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX24 n
7E 30 30 32 34 20 a 0D
~XX25 n
7E 30 30 32 35 20 a 0D
~XX26 n
7E 30 30 32 36 20 a 0D
~XX27 n
7E 30 30 32 37 20 a 0D
~XX28 n
7E 30 30 32 38 20 a 0D
~XX29 n
7E 30 30 32 39 20 a 0D
~XX30 n
7E 30 30 33 30 20 a 0D
~XX31 n
7E 30 30 33 31 20 a 0D
~XX32 n
7E 30 30 33 32 20 a 0D
~XX33 1
7E 30 30 33 33 20 31 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX34 n
7E 30 30 33 34 20 a 0D
~XX35 1
7E 30 30 33 35 20 31 0D
~XX35 2
7E 30 30 33 35 20 32 0D
~XX35 3
7E 30 30 33 35 20 33 0D
~XX35 4
7E 30 30 33 35 20 34 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX36 1
7E 30 30 33 36 20 31 0D
~XX36 2
7E 30 30 33 36 20 32 0D
~XX36 3
7E 30 30 33 36 20 33 0D
~XX37 1
7E 30 30 33 37 20 31 0D
~XX37 2
7E 30 30 33 37 20 32 0D
~XX37 3
7E 30 30 33 37 20 33 0D
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
58
Nederlands
Functielijst RS232-protocol
Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F
Function
Power ON
Power OFF
Power ON with Password
Resync
AV Mute
Mute
Freeze
Unfreeze
Zoom Plus
Zoom Minus
Up (Pan under zoom)
Down (Pan under zoom)
Left (Pan under zoom)
Right (Pan under zoom)
Direct Source Command
Display Mode
Brightness
Contrast
Sharpness
Color
TM
BrilliantColor
Degamma
Color Temp.
Color Space
XX=00-99, projector's ID,
XX=00 is for all projectors
Note : There is a <CR> after all ASCII commands
0D is the HEX code for <CR> in ASCII code
XX=01 99, projector's ID, XX=00 is for all projectors
Description
~nnnn = ~0000 (a=7E 30 30 30 30) - ~9999(a=7E 39 39 39 39)
On
Off
On
Off
HDMI
VGA 1
VGA 2
S-Video
Video
Presentation
Bright
Movie
sRGB
User
Blackboard
Classroom
3D
n = 0 (a=30) ~ 100 (a=31 30 30)
n = 0 (a=30) ~ 100 (a=31 30 30)
n = 0 (a=30) ~ 31 (a=33 31)
Red Gain
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Green Gain
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Blue Gain
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Red Bias
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Green Bias
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Blue Bias
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Cyan
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Yellow
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Magenta
n = -50 (a=2D 35 30) ~ 50 (a=35 30)
Reset
n = 0 (a=30) ~ 10 (a=31 30)
Film
Video
Graphics
PC
Warm
Medium
Cold
Auto
RGB
YUV
