5.10 Seat Memory Position
The control system on the Q700-UP M/F has 5 predefined seat
memory positions. Each memory location has a set of factory
seat positioning presets:
Seating, Stand-Up, Lie-Down, Transfer and Relax. There is
a 6th Memory position (Custom Position) that can be used
as a customized seat position. The Seat actuators are all
working with a feedback system to track their positions and
movements.
This is important:
a. to reach the required memory position.
b. to prevent mechanical clashes of the seat.
c. to operate the actuators especially towards the memory
positions in an ergonomic, smooth and safe way.
Although there is one free programmable seat Memory
position, all predefined Memory positions, if not suitable
for the user, can be changed and customized to the needs
required.
The software takes into account the range of the available
mechanical movements and also all safety aspects.
Seat function:
The seat function as described in 5.15 is a predefined
'standard' seat position.
It also creates the possibility to always return to this 'standard'
seat position when you are using other memory positions
(Standing, Relax or Lie down). This can be achieved by pulling
the joystick backwards.
5.11 Electric Seating function
Seat function:
The Q700-UP series has a seat function that is a predefined
'standard' seat position.
It also creates the possibility to always return to this 'standard'
seat position when you are using other memory positions
(Relax or Lie down). This can be achieved by pulling the
joystick backwards.
Q700-UP M/F Rev.A
5.12 Electric Lie Down function
The Quickie Q700-Up M/F has an electric lie down function.
This function makes it possible for the user to lie down in the
wheelchair.
WARNING!
• Only use the lie down function on a sound and level surface.
• The lie down procedure automatically locks the front and
rear castor arms.
• If the locking procedure fails the chair will automatically
stop in a safe position. The seat can always be returned to
the normally seated position in any mode.
5.13 Electric Relax function
The Quickie Q700-Up M/F has an electric relax seating
function. This function makes it possible for the user to come
to a relaxed seating position in the wheelchair.
5.14 Electric Transfer function
The Quickie Q700-UP M/F has an electric transfer function.
This function makes it possible for the user to transfer in and
out of the wheelchair.
5.15 Electric Standing function
The Quickie Q700-UP M/F has an electric Standing function.
This function makes it possible for the user to stand up in the
wheelchair.
DANGER:
The use of knee fixation and chest straps are mandatory when
using the standing function.
WARNING!
• Before using the standing function ensure that the front
knee fixation is in place.
• Only use the standing function on a sound and level surface.
• The stand up procedure automatically locks the front and
rear castor arm suspension (MWD).
• A load shift to the front can prevent suspension locking.
• The stand up procedure automatically lowers the front anti
tip wheels (FWD).
• Do not change height setting of front anti tip wheels as that
would have a negative effect on static/dynamic stability in
standing function.
• If the locking procedure fails the chair will automatically
stop in a safe position. The seat can always be returned to
the normally seated position in any mode.
19
