10.0 Trouble shooting
If the wheelchair is not working as it should, check the following points.
• Check whether the batteries are charged.
• Turn the wheelchair off and then back on again.
• Check whether the battery plugs are all securely in place.
• Check whether the freewheel lever is in the DRIVE position
• Check the position of the speed regulator.
• Make sure that the controller isn't locked & Controller
If the problem has not been resolved:
• Consult the trouble shooting section for the controller & Controller
11.0 Technical specifications: Applicable norms / standards
This product complies with the regulations and guidelines for medical aids and carries a CE symbol.
The product meets the requirements and standards below. These are checked by independent institutions.
Definition / description
Standard
EU guideline
Applicable as mentioned in Appendix 1
93/42 EEC
EN 12182: 2012
Assistive products for persons with disability - General requirements and test
Class B
methods"
Q 700 Up-M/F
EN 12184: 2014
Electrically powered wheelchairs, scooters and their chargers - Requirements
Class B
and test methods
Q 700 Up-M/F
ISO 7176-8: 2014
Requirements and test methods for impact, static and fatigue strengths
ISO 7176-9: 2009
Climate tests for electric wheelchairs
ISO 7176-14: 2008
Requirements and test methods for control systems for electric wheelchairs
1997
ISO 7176-16: 2012
Requirements for resistance to ignition of upholstered parts
ISO 7176-19: 2008
"Wheelchairs - Part 19: Wheeled mobility devices for use as seats in motor
vehicles:
The Q-series meet the crash test requirements as described in ISO 7176-19"
Q 700-Up M/F
40
Test Dummy
Weight
"SEDEO
Ergo UP"
120 kg
SEDEO Ergo UP
120 kg
N/A
N/A
N/A
N/A
SEDEO Ergo UP
75 kg
Q700-UP M/F Rev.A
