QUICK INSTALLATION GUIDE
1 STATEMENT
Thanks for using our product.
This manual is applicable for standard DVR including only a few instructions for product operations. For more
information, please read the CD.
Notice:
1. Please verify each camera is connected with dvr to ensure every channel is shown
2. All channels are showing or not depend on remote (DVR-side) and your local (smartphone-side)
network conditions.
3. All channels can be viewed separately
4. Max. 16CH video sync viewing on your smartphone
2 APPEARANCE & INTERFACE INSTRUCTIONS
2.1 Front panel
2.2 Rear panel
No.
Function
1
Video Input
3
VGA Output
5
Audio Input
7
USB Interface
9
Power
No.
Function
1
HDD indicator
3
IR Receiver
No.
Function
2
Audio Output
4
HDMI Output
6
WAN port
8
RS485
3
No.
Function
2
Power Indicator
