Check the installation in accordance with the installation instructions and ensure that the drive rollers are
not applied. Check that the battery is properly connected, check the condition of the battery and that a
voltage of 12 V is present at the control unit.
Please ensure that the battery isolation switch is on.
Activate the remote control handset by sliding the slide switch to "On"-I (Fig. 5A). The green LED on the
remote control handset (Fig. 5H) starts to flash slowly.
Press the reset button (Fig. 3A) on the control unit. All three LED's on the control unit (Fig. 3B, 3C & 3D)
will flash slowly.
Press both forwards (Fig. 5B) and reverse (Fig. 5C) button on the remote control handset for about 3
seconds. Then the handset buzzer will give a short beep to confirm that the synchronisation is complete.
After successful synchronisation, the green LED on the control unit (Fig. 3B) and on the remote control
handset (Fig. 5H) will illuminate continuously.
The single/twin axle function switch (Fig. 3S/T): The EN
suitable for both single axle and twin axle caravans. You just need to pull the single/twin axle function switch
(Fig 3S/T) on the control unit, so that the manoeuvring system can be used for a single axle caravan or a twin
axle caravan (for 2 motor use but also for 4 motor use). In the twin axle function the all wheels will drive but at
a different speed.
The switch standard pre-selected for single axle use (Fig 3S). For twin axle use, just move the switch to the
twin axle position (Fig. 3T). When move the single/twin axle function switch, the battery power isolation switch
(29) must be turned off.
OPERATION - GETTING STARTED
Please make sure you read the safety instructions very carefully and make sure that you
follow these guidelines!
Make sure that the battery that supplies the system is fully charged and in good condition.
Make sure that the caravan is free from the vehicle and the handbrake is on. Also make sure
that the corner steady feet are fully raised.
Turn on the battery power isolation switch (29).
Activate the manoeuvring system by move slide switch to "On"-I on the remote control (Fig. 5A). The green
LED (Fig. 5H) on the remote control handset will illuminate and you will hear a short beep. The remote control
is ready for use.
Press at the same time, during at least three seconds, the two buttons for engaging the motor powered rollers
(Fig. 5I). The blue LED (Fig. 5H) will blink fast during these three seconds and every second there will be a
beep. This warns you that the system will be activated!
After these three seconds the motor powered rollers will be pressed against the tyre and the blue LED will
illuminate constant. Now you can release the two buttons. When the motor powered rollers are pressed on the
tyre strongly enough, the blue LED will switch off and is the system ready to manoeuvre. The colour of the
traction indicator label (Fig. 11A) should be into the green area.
Before operating the manoeuvring system, release the handbrake.
Now you can choose the movements according the symbols shown on the remote control. Straight forward (Fig.
5B), straight reverse (Fig. 5C), left forward (Fig. 5D), left reverse (Fig. 5F), right forward (Fig. 5E), right
reverse (Fig. 5G).
In addition, the left forward (Fig. 5D) and right reverse (Fig. 5G) buttons or right forward (Fig. 5E) and left
reverse (Fig. 5F) buttons may be pressed at the same time to turn the caravan around on its own axis without
moving forward or backward (this function just can work under the "single-axle function").
When you drive straight forwards or reverse (press button 5B or 5C), it is also possible to adjust the direction
by additional pressing button 5D or 5E (when driving forwards) or button 5F or 5G (when driving reverse).
Because of the "soft start" technology, the caravan will slowly speed up. Because of the "soft stop" technology,
the caravan will stop slowly. This allows you to manoeuvre your caravan even more accurately without any
shocks.
WARNING: When the buttons on the remote control handset are released, the caravan will
slowly stop after 0.5 second and continue to move about 6cm (depending on final speed).
When the buttons of the remote control handset are released when the system is still in the
"soft start" stage (slowly speed up), the caravan will stop immediately.
®
