INSTALLATION
Rotating the motor
EN 14
The motor can discharge air in 5 directions (to the 4 sides or upwards).
Rotate the motor housing to select the correct discharge direction.
Changing the discharge direction
1. Flip the edge extractor panel downwards.
2. Remove the grease filters.
3. Unscrew the motor housing.
4. Rotate the motor housing so that the discharge opening is on the
desired side. For discharge upwards, unscrew the motor out of the
motor housing. Rotate the motor so that the discharge opening is
facing upwards and screw the motor back into the motor housing..
7x
5. Screw the motor housing onto the extraction unit.
8x
8x
7x
7x
7x
