5. Instrument and control functions
66
User manual English
5.14 Odometer
This displays the total distance (in kilometers or miles) traveled
while the power was on. The odometer cannot be reset.
5.15 Remaining assist distance
This displays an estimate of the distance (in kilometers or miles)
that can be traveled with assist on the residual battery capacity
of the battery installed. If you switch the assist mode when the
remaining assist distance is displayed, the estimate of the
distance that can be traveled with assist changes. The remaining
assist distance estimate cannot be reset.
TIP
• The remaining assist distance changes depending on the
riding situation (hills, headwind, etc.) and as the battery runs
out/low. See point 4.4 on page 8.
• If in "Off mode", '- - - -' is displayed.
5.16 Battery capacity (%)
This displays the power remaining in the battery.
The residual battery capacity display cannot be reset.
5.17 Cadence
This displays your pedaling speed in revolutions per minute.
The pedaling cadence display cannot be reset.
TIP
If you pedal backwards, '0.0' is displayed.
5.18 Light on/off
Each time you press the light switch, the light switches between
"On" and "Off".
When the light is activated/turned on, the back light of the display
also lights up.
NOTICE
If the battery becomes exhausted while cycling and no longer
provides power assist, the light will remain on for about 2 more
hours. Remember this, when you may be cycling in the dark.
All manuals and user guides at all-guides.com
5. Instrument and control functions
5.19 Pushing assist
When you are on or off the bicycle and start moving it, you
can use pushing assist without pedaling the bicycle.
To use pushing assist, press and hold the pushing assist switch.
Pushing assist will stop in the following situations:
• When you release the pushing assist switch.
• If you press another switch at the same time.
• When you start to pedal.
• If your bicycle speed exceeds 6 km/h.
• If you select Off mode.
• If the wheels are not turning (when braking or coming
into contact with an obstacle, etc.).
5.20 Clock and km/mile settings
Use the following steps to set the time and km/mile settings:
1. Make sure that the display is mounted on the display holder,
and that the display unit is turned off.
2. Press the power switch while holding the function select switch.
3. When the "hour" on the clock begins to flash, release the
switches.
4. Use the assist mode switches (up & down) to set the "hour".
5. Press the function select switch, and the "minutes" on the clock
will begin to flash.
6. Use the assist mode switches (up & down) to set the "minute".
NL
EN
67
